To install the lid, with its support flanges upward lead the flanges over the tabs of the lid support brackets.
Slide it all the way in until the lid drops into position, rest on the supports, and is retained front to back.
It's as easy as that. Enjoy the many pan size and configuration options possible with this patent pending
flexible lid system.
With the Multipan Flexible Lid Option, there are solid and vented lids. Additionally, each are both provided
with and without pan guides. This provides the maximum flexibility whether you choose to use 1/3, 1/2, full
size pans or a combination of pan sizes. For the below examples, we will use a 2x3 PHU configuration and
show a few of the 3 wide shelf configuration options and their lid orientations.
1. Configured for 1/3 size pans;
a. Wells 1 & 2 with lids oriented with the pan
guides to the right.
b. Well 3 using a lid with no pan guide. This
provides pan guides for all three 1/3 size
pans, as shown.
2. Configured for one - 1/2 size pan and one - 1/3
six pan;
a. Well 1 with a lid oriented with the pan guide
to the left.
b. Well 2 with a lid oriented with the pan guide
to the right.
c. Well 3 using a lid with no pan guide. This
provides pan guides between the 1/2 size
pan and 1/3 size pan.
3. Configured for one full size pan;
a. Well 1 with a lid oriented with the pan guide
to the left.
b. Well 2 with a lid with no pan guide.
c. Well 3 with a lid oriented with the pan guide
to the right.
These are just a few of the multiple pan options possible that you can configure without the use of tools and
with the standard parts included with your unit.
