CAUTION:
This manual is Copyright © 2020 Duke Manufacturing Co. All rights reserved.
Reproduction without written permission is prohibited. Duke is a registered
Please read this manual completely before attempting
to install, operate or service this equipment
WARNING: Cancer and Reproductive Harm -
www.p65warnings.ca.gov
trademark of the Duke Manufacturing Co.
Installation and
Operation Manual
P/N 118738
REV D 01/23/2020
Advertisement
Table of Contents
Related Manuals for Duke INTERSECT
Summary of Contents for Duke INTERSECT
- Page 1 WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov This manual is Copyright © 2020 Duke Manufacturing Co. All rights reserved. Reproduction without written permission is prohibited. Duke is a registered P/N 118738 trademark of the Duke Manufacturing Co.
-
Page 2: Table Of Contents
D. NETWORK REQUIREMENTS ............................... 5 II. INSTALLATION INSTRUCTIONS ..............................6 A. HARDWARE INSTALLATION ............................... 6 B. CONNECTING THE iNTERSECT ..............................7 C. Ethernet PHU Connection ................................. 7 III. KITCHEN MINDER SETUP ................................8 A. Connection to Kitchen Minder ..............................8 B. - Page 3 • Do not operate this equipment if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. • This equipment should be serviced by qualified personnel only. Contact the nearest Duke authorized service facility for adjustment or repair.
-
Page 4: General Information
I. GENERAL INFORMATION DELIVERY AND INSPECTION Duke Manufacturing Co. does everything within its power to ensure you receive your Duke iNTERSECT in good condition. All components of the kit have been carefully inspected before they were packaged for shipping. The material used and manner in which the kit is packed has successfully passed the carrier’s transit test. -
Page 5: Tools / Materials Required For Installation
NETWORK REQUIREMENTS Duke iNTERSECT requires an internet connection to maintain software updates to iNTERSECT, new PHU product recipe information, and firmware updates to PHU’s when applicable. Please note that whether you have in-house IT representation or utilize an outside source, the following network modifications will need to be applied. -
Page 6: Installation Instructions
Fig A-2 h. Attach power cord to intersect unit. Fig A-3 i. Plug the power cable into an open 120-240 VAC outlet. j. Using power Switch turn on the iNTERSECT – Blue light must be lit solid. Phillips Screws Blue Light... -
Page 7: Connecting The Intersect
“ETHERNET PHU” label on the iNTERSECT. (ports 6, 7, 8) Fig C-1. NOTE: Power to each of the PHU’s should be placed in the OFF position. The iNTERSECT supports up to 3 Ethernet PHU’s as shipped. An additional Ethernet switch will allow for expanded capacity for more PHU’s. -
Page 8: Kitchen Minder Setup
Ethernet Cables NOTE: iNTERSECT supports up to 2 Kitchen Minder COM channels for up to 6 PHU’s, or a maximum of 48 wells. Connection to Kitchen Minder a. Install up to 2 Cat5e cables from master PHU units to iNTERSECT unit. - Page 9 A green notification will display indicating if successful. Note: If multiple PHU’s are being configured, there may not be enough ports to connect all of the PHU’s into the iNTERSECT and the laptop. A PHU can be disconnected from the iNTERSECT once it has been discover without interfering with the port mapping.
- Page 10 Installation and Operation of: iNTERSECT III. KITCHEN MINDER SETUP - continued Connecting Your New Duke HS2 Ethernet PHUs to Kitchen Minder... NOTE: An internet connection is necessary for Recipe Management, Technical Support, and Intersect Software Updates. These network configurations are required for...
-
Page 11: Intersect Network Diagram
Installation and Operation of: iNTERSECT Intersect Network Diagram Firmware Analytics Updates Remote Recipe Support Duke Connected Int ernet Int ernet Int ernet Management Equipment Platform Powered by ISP POP BK Store Premise Firewall 443 Outbound Secure Tunnel Switch / VLAN Duke Intersect Version 1.0... -
Page 12: Intersect Specifications
Installation and Operation of: iNTERSECT IV. iNTERSECT SPECIFICATIONS 100-240VAC - 50/60HZ HEIGHT WIDTH DEPTH WEIGHT PART PART NUMBER NAME AMPS NEMA Duke 118322 5-15P 12.12 12.32 2.65 9.90 iNTERSECT REPLACEMENT PARTS LIST DESCRIPTION Part No. DUKE iNTERSECT 118322 Mounting Bracket 118745 25Ft.
