Installation Instructions
Mounting Height, Clearance, & Ducting
12
D
n .
m i
E
n .
m i
F
x .
m a
Hood Heights
minimum ducted (A)
minimum recirculating (B)
maximum (C)
Ceiling Heights
minimum ducted (D)
minimum recirculating (E)
maximum (F)
Modena Island Use, Care, and Installation Guide
A
n .
m i
B
n .
m i
C
x .
m a
i n .
.
" m
a x
2 4
" m
3 4
"
3 6
Standard Extension
Duct Cover Duct Cover
28" 43"
32" 46"
50" 80"
88" (7' 4") 103" (8' 7")
92" (7' 8") 106" (8' 10")
120" (10') 150" (12' 6")
