List of Materials

(3) Wire Nuts
Ducting, conduit and all installation tools
Cable locking connector (if required by local codes)
Duct cover extension kit
Recirculating kit
10
Parts Supplied
2 - Top duct covers
2 - Bottom duct covers
1 - 8" round damper (pre-installed)
1 - Hood body w/ blower (pre-installed)
(4) #6 x 1-1/2" (4) ø12 OD / ø5
wood screws ID Washers
(1) M4 x 12 (20) M4 x 8 pan-head
safety screw
machine screws
Parts Not Supplied
Modena Island Use, Care, and Installation Guide
1 - Top support frame
Cut-Out Shaded Area
A
1 - Support frame bracket
1 - Bottom support frame
2 - Lateral support brackets
4 - LumiLight LED, 6W
1 - Aluminum mesh filter
1 - Hardware package
(4) 3/16 x 1/4 pan-head
machine screws
M O D E N A
I S L A N D
Front of Hood
C L
B
1 - Paper ceiling
template
C O R E
