Wiring Diagram - Zephyr ZMD-M90BS Use, Care And Installation Manual

Wiring Diagram

ZMD-M90BS/ZMD-E42BS
BODY
Power consumption shown for default 600 CFM blower configuration
ACT 390 CFM - Fan Max. 393W @ 3.3A
ACT 290 CFM - Fan Max. 365W @ 3.0A
30
CIRCUIT DIAGRAM
MOTOR
WHITE
Modena Island Use, Care, and Installation Guide
VOLTS HZ MAX. AMPS
120 60
RED
YELLOW
BLUE
BROWN
GREY
WHITE
GREEN
BODY
YELLOW
LED
LED
LED
LED
C O R E
M O D E N A
I S L A N D
5
YELLOW
