/// Using the "Quick mix" function
Quick
mix
Fast
0:00:00
10:00:00
0 500
Note: When the tempering function is activated, the "Quick mix" function is not available�
24
A
IKA MATRIX 2.0 mL
0:00:00
0:00:00
25.0 0
Fast actual ºC actual rpm
38.0 500
Set ºC Set rpm
A
IKA MATRIX 2.0 mL
0:00:01
0:00:12
25.0 220
Fast actual ºC actual rpm
38.0 500
Set ºC Set rpm
A
IKA MATRIX 2.0 mL
0:00:00
0:00:12
25.0 0
Fast actual ºC actual rpm
38.0 500
Set ºC Set rpm

Menu navigation and structure

/// Menu navigation
G H
› Press the "Menu" button (G)�
› Select right menu item by touching the speed (+) button (L)�
Select left menu item by touching the speed (-) button (K)�
› Confirm and enter the selected menu item by touching the mixing button (J)�
a) Select desired sub-menu by touching speed (+) button (L) or speed (-) button (K)�
Activate / deactivate a function by touching the mixing button (J)�
b) Activate the editing function to a sub-menu by touching the mixing button (J)�
Edit the value by touching speed (+) button (L) or speed (-) button (K)�
Confirm the value by touching the mixing button (J)�
Save the new value either by touching the "Back" button (H) or by selecting "OK" with
mixing button (J)�
Note: the selected menu option is highlighted in blue on the screen and can be edited by
touching (at the same time the color change to yellow) on the mixing button (J)�
Back
A Menu
IKA MATRIX 2.0 mL
0:00:00 0:00:00
Menu
25.0 0
Fast actual ºC actual rpm
100.0 300
Mixing
Set ºC Set rpm
Menu
Menu
Note: When touching the "Menu" button (G), the system skips directly back to the
working screen�
When touching the "Back" button (H), the system skips back to the previous menu
level screen�
L
K
J
Menu
+
A B
...
C
-
Timer
Back
Timer
Mixing
Tempering
-
+
Timer
Mixing
Tempering
...
