Campbell Hausfeld IN729000AV Operating Instructions Manual

See Warranty on page 10 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . .1
Safety Guidelines . . . . . . . . . . . . . . . . .1
Important Safety Instructions . . . . . . .2
Tool Components and Specifications . .2
Operating the Tool . . . . . . . . . . . . . . . .4
Recommended Hookup . . . . . . . . . . . .5
Maintenance . . . . . . . . . . . . . . . . . . . . .7
Storage . . . . . . . . . . . . . . . . . . . . . . . . .7
Fasteners . . . . . . . . . . . . . . . . . . . . . . . .8
Troubleshooting Chart . . . . . . . . . . . . .9
Warranty . . . . . . . . . . . . . . . . . . . . . . .10
Description
This tool is designed for decorative trim,
molding, window casings, furniture
trim, picture frame assembly, cabinetry,
casebacks, and crafts . Features include:
convenient top loading magazine
which holds up to 100 brads or staples,
adjustable depth control, adjustable
exhaust nose .
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit . Check
for loose, missing or damaged parts .
Make sure to tighten fittings, bolts,
etc ., before putting unit into service .
Check to be sure all supplied accessories
are enclosed with the unit . In case of
questions, damaged or missing parts,
please call 1-800-543-6400 for customer
assistance .
© 2009 Campbell Hausfeld/Scott Fetzer
Figure 1 - Model SB524000
Safety Guidelines
This manual contains information that is very important to know and understand .
This information is provided for SAFETY and to PREVENT EQUIPMENT PROBLEMS .
To help recognize this information, observe the following symbols .
NOTe: Information that requires special attention .
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.chpower.com
2 inch 2-in-1
Nailer/Stapler
ReaD & FOllOW all INSTRUCTIONS
Save TheSe INSTRUCTIONS
DO NOT DISCaRD
Danger indicates an imminently hazardous situation which, if
not avoided, WILL result in death or serious injury.
Warning indicates a potentially hazardous situation which, if
not avoided, COULD result in death or serious injury.
Caution indicates a potentially hazardous situation which, if not
avoided, MAY result in minor or moderate injury.
Notice indicates important information, that if not followed,
may cause damage to equipment.
SB524000
IN729000AV 9/09
