Pin Nailer
CHn71500
3
Load
fasteners. See manual for further information regarding
length and type of fasteners.
Press
magazine latch button
and pull magazine open.
Setup
Like a Pro
Visit us at
chpower.com
Setup
Like a Pro
Easy Setup Guide
Projects are easier with
Campbell Hausfeld products.
Thank you for deciding to purchase a Campbell
Hausfeld product. We are dedicated to providing
tools that help you to complete your projects
Like a Pro.
© 2010 Campbell Hausfeld/Scott Fetzer
Load
pins with points all the
way into the groove.
1
Close
regulator,
compressor and
Allow
maximum pressure.
NOTICE: To operate this tool you will need
at least a 1 gallon compressor.
IN730500AV 6/10
Close
magazine.
2
pressure
Attach
Turn on
to regulator outlet.
Adjust
tank to reach
knob so outlet
pressure is between
60 psi and 100 psi.
4
Attach
airhose to nailer inlet.
CHN71500 — Air Powered Pin Nailer
air hose
regulator
100
60
psi
psi
coupler on
