Campbell Hausfeld CHN90498 Operating Instructions Manual

See Warranty on page 8 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . 1
Unpacking . . . . . . . . . . . . . . . . . . . . . . 1
Safety Guidelines . . . . . . . . . . . . . . . . 1
Important Safety Information . . . . . . 1
Tool Components and
Specifications. . . . . . . . . . . . . . . . . . . . 2
Operating Instructions . . . . . . . . . . . . 4
Lubrication . . . . . . . . . . . . . . . . . . . . 4
Recommended Hookup. . . . . . . . . . 4
Sequential Trip Safety Mechanism . .5
Operating a Sequential Trip Nailer. .5
Work Contact Element (WCE) . . . . . 5
Loading/Unloading The Tool. . . . . . 5
Adjusting the Nail Penetration . . . . 5
User-Maintenance Instructions . . . . . 5
Clearing A Jam From The Tool . . . . 5
Technical Service . . . . . . . . . . . . . . . 6
Fastener And Replacement Parts . . 6
Tool Repair . . . . . . . . . . . . . . . . . . . . 6
Assembly Procedure For Seals . . . . . 6
Fastener Interchange Information. . . 6
Troubleshooting Chart . . . . . . . . . . . . 7
Warranty . . . . . . . . . . . . . . . . . . . . . . . 8
Description
This nailer is designed for decorative
trim, molding, window casings,
furniture trim and picture frame
assembly. Features include: convenient
rear loading magazine which holds
up to 100 nails, no-mar tip, adjustable
exhaust, single cycle trigger, quick clear
nose, and an adjustable depth of drive
mechanism.
Campbell Hausfeld Nailers meet or exceed Industries' Standards as set forth by the American
National Standard Institute/International Staple, Nail and Tool Association in ANSI/ISANTA
SNT-101-2002.
© 2010 Campbell Hausfeld/Scott Fetzer
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit. Make sure
to tighten fittings, bolts, etc., before
putting unit into service.
Safety Guidelines
This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
information, that if not followed, may
cause damage to equipment.
NOTE: Information that requires special
attention.
Important Safety Instructions
INSTRUCTIONS PERTAINING TO A
RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.chpower.com
Brad Nailer
Model NB003006
Danger indicates
an imminently
Locate model and date code on
tool and record below:
Model No.: _____________________
Date Code: _____________________
Warning indicates
a potentially
Caution indicates
a potentially
should always be followed, including
the following:
CALIFORNIA PROPOSITION 65
Notice indicates
important
contain chemicals known to the State
of California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
You can create dust when
you cut, sand, drill or grind
materials such as wood,
paint, metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer, birth
defects, or other reproductive harm.
Wear protective gear.
NB003006
Retain these numbers for
future reference.
When using tools,
basic precautions
This product or
its power cord may
IN703700AV 2/10
