Framing Nailer
CHn70900
© 2010 Campbell Hausfeld/Scott Fetzer
3
Load
fasteners. See manual for further information regarding
length and type of fasteners.
Load
Setup
Like a Pro
Visit us at
chpower.com
Setup
Like a Pro
Easy Setup Guide
Projects are easier with
Campbell Hausfeld products.
Thank you for deciding to purchase a
Campbell Hausfeld product. We are dedicated
to providing tools that help you to complete your
projects Like a Pro.
Pull
nails into rear slot of magazine.
Release
pusher.
1
Close
regulator,
compressor and
Allow
maximum pressure.
NOTICE: To operate this tool you will need
at least a 1 gallon compressor.
IN730400AV 2/10
pusher back over nail clip.
2
pressure
Attach
Turn on
to regulator outlet.
Adjust
tank to reach
knob so outlet
pressure is between
70 psi and 120 psi.
4
Attach
coupler on air
hose to nailer inlet.
CHN70900 — Air Powered Framing Nailer
air hose
regulator
70
120
psi
psi
