Campbell Hausfeld IN720501AV Operating Instructions Manual

See Warranty on page 10 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . .1
Safety Guidelines . . . . . . . . . . . . . . . . .1
Important Safety Instructions . . . . . . .2
Tool Components and Specifications. .2
Operating the Nailer . . . . . . . . . . . . . .4
Fasteners . . . . . . . . . . . . . . . . . . . . . . . .7
Troubleshooting Chart . . . . . . . . . . . . .8
Warranty . . . . . . . . . . . . . . . . . . . . . . .10
Description
This nailer is designed for decorative
trim, molding, window casings,
furniture trim and picture frame
assembly. Features include: convenient
top loading magazine which holds up
to 100 nails, no-mar tip, adjustable
exhaust, single cycle trigger, quick clear
nose, and an adjustable depth of drive
mechanism.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit. Make sure
to tighten fittings, bolts, etc., before
putting unit into service.
ReaD & FOllOW all INSTRUCTIONS
Save TheSe INSTRUCTIONS
DO NOT DISCaRD
Campbell Hausfeld Nailers meet or exceed Industries'
Standards as set forth by the American National Standard
Institute/International Staple, Nail and Tool Association in
ANSI/ISANTA SNT-101-2002.
© 2009 Campbell Hausfeld/Scott Fetzer
Figure 1 - Model NB006750
Safety Guidelines
This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
hazardous situation which, if not
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.chpower.com
Finishing
Nailer
avoided, MAY result in minor or
moderate injury.
information, that if not followed, may
cause damage to equipment.
NOTe: Information that requires special
attention.
Danger indicates
an imminently
Locate model and date code on
Warning indicates tool and record below:
a potentially
Model No. ______________________
Date Code ______________________
Caution indicates a
potentially
NB006750
Notice indicates
important
Retain these numbers
for future reference.
IN720501AV 11/09
