Universal
10ft X 20ft
™
10ft8in Wide x 20ft Deep x 5ft10in Side Height /
8ft11in Center Height
King Canopy Item #: C61020PC
With 6 Legs, White Drawstring Cover,
Elastic Ball Straps & Foot Pads.
WARNING:
Keep all flame and heat sources
away from this tent fabric. Meets
the flammability requirements of
Distributed by:
CPAI-84 Sec 6 and NFPA 701 It is not
PIC America, LTD.
fire proof. The fabric will burn if left in
8009 Purfoy Road • Fuquay-Varina, NC 27526
continuous contact with any flame source.
1-800-800-6296 • www.kingcanopy.com
Advertisement
Table of Contents
Related Manuals for KING CANOPY Universal C61020PC
Summary of Contents for KING CANOPY Universal C61020PC
- Page 1 10ft X 20ft ™ 10ft8in Wide x 20ft Deep x 5ft10in Side Height / 8ft11in Center Height King Canopy Item #: C61020PC With 6 Legs, White Drawstring Cover, Elastic Ball Straps & Foot Pads. WARNING: Keep all flame and heat sources away from this tent fabric.
- Page 2 PARTS LIST 5X8PC 18 pc 68” Powder Coated Pipe 4X6PC 6 pc 52” Swaged Powder Coated Pipe 3WPC 6 pc 3-Way Connectors 4WPC 3 pc 4-Way Connectors BALLW 44 pc Elastic Ball Straps PFOOT 6 pc Plastic Foot Pads TDS10206-5 1 pc White Drawstring Cover CCLIP...
- Page 3 FRAME ASSEMBLY Step 1 Place all corners and pipe on the ground as shown. The 52” swaged pipes are used to form the length of the canopy. Step 2 Start with the center and complete the center frame first. Then assemble each side. NOTE: Attach the cover before inserting the legs.
- Page 4 COVER ASSEMBLY Step 1 Unfold the cover with the grommets toward the cover’s bottom and place over the frame. Step 2 Begin attaching the cover with the elastic ball straps by inserting the elastic cord of the ball strap underneath the cover and through the grommet.
- Page 5 LEGS ASSEMBLY NOW, CONNECT THE LEG POLES TO THE ROOF ASSEMBLY WITH THE COVER ALREADY POSITIONED ON TOP OF THE UNIT. Step A: First insert the pipes for the middle poles into the 3- and 4-way connectors, and then connect the end leg pipes in the same way.
- Page 6 ANCHORING YOUR UNIT This canopy is designed for use as a temporary structure. After assembly, the canopy MUST BE securely anchored to the ground to prevent damage from winds. Your canopy will act like a kite in the wind if not properly and securely anchored to the ground.
- Page 7 IMPORTANT NOTICE: PLEASE READ CAREFULLY We are confident that you will be completely satisfied with your King Canopy unit. Please take a moment to read the very important information below, and call us with any questions you may have. King Canopy/PIC America, LTD. has no control over wind, snow, ice, rain or any other weather condition and we are in no way responsible for any damage caused by the canopy or to the canopy.
- Page 8 Improper Anchoring, Strong Winds, Rain, Snow, Ice NOT put away your Instant Canopy while wet or damp. This King Canopy/ PIC America, LTD. does not guarantee these promotes mildew. Store DRY. For best results in keeping your canopies under strong weather conditions (including snow top clean and avoiding small tears, it is recommended that &...
