Westin 59-8202 Installation Instructions Manual

PART ONE: WJ2 REAR BUMPER INSTALLATION ONLY
ITEM QUANTITY
1 1
2 2
3 1
4 1
5 2
6 2
7 4
8 2
9 4
10 8
11 8
12 8
13 4
14 4
15 4
16 4
17 8
18 4
19 2
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
Westin Automotive Products, Inc.
320 W. Covina Blvd
San Dimas, Ca. 91773
P.N.: 75-598202-RevB ECO #: W18-0140
APPLICATION:
PART NUMBER:
*See Page 7 for components associated with Tire Carrier Install*
LICENSE PLATE RELOCATOR BRACKET
TRAILER PLUG RELOCATOR BRACKET
QUARTER PANEL CLOSEOUT PANEL (1 DRIVER, 1 PASSENGER)
M4 HEX SOCKET BUTTON HEAD SCREW
M6 HEX SOCKET BUTTON HEAD BOLT
M8 SQUARE NECK CARRIAGE BOLT
INSTALLATION INSTRUCTIONS
WJ2 REAR BUMPER
WJ2 REAR BUMPER W/ TIRE CARRIER
2018-2019 Jeep Wrangler JL (Excl. Wrangler JK)
59-82025, 59-82035
CONTENT
DESCRIPTION
REAR BUMPER ASSEMBLY
M14 NUT PLATE
LIGHTED SCREW
M6 SPLIT LOCK WASHER
M8 SERRATED FLANGE NUT
M6 HEX NUT
M14 HEX HEAD CAP SCREW
M14 FLAT WASHER
M14 SPLIT LOCK WASHER
M4 FLAT WASHER
M4 SPLIT LOCK WASHER
M4 HEX NUT
M6 FLAT WASHER
1
Thank you for choosing Westin products
for additional installation assistance please call
Customer Service (800) 793-7846
www.westinautomotive.com
TOOLS NEEDED
18MM SOCKET
18MM WRENCH
10MM WRENCH
RATCHET
TORQUE WRENCH
ALLEN WRENCH
DRILL MOTOR
1/2" DRILL BIT
15MM SOCKET
HEAT GUN
DATE: 10/03/18
