CD Automation REVEX 1Ph 30A User Manual page 31

REVEX
1PH from 30A to 40A
9.4.3 Advanced Setup Menu
This section describes each item on the advanced setup menu. Use this menu to configure the power
switching, closed loop control of power and adjustable settings for data logging and heater bakeout. The
password to access this menu is 10.
Parameter Name
Firing Type
Choose the firing mode
Parameter Name
Min Cycles
Set the minimum number of On
cycles and off cycles for burst firing
Soft Start
Set the duration of the soft start in
increment of 100mSec. The power
controller ramps set to point changes
over the time set here. For more
information see "Firing type" page:
Soft Start with Burst Firing and Soft
Start with Phase Angle
Start Ramp
Set the number of half cycles over
which the power ramps each time the
output turns on
Delay
Set the firing delay degrees. Applies
to burst firing with delay trigger
Cycle time
Set the duration of one on-off cycle in
increments of 50mSec.
Applies to zero crossing
Description
Option
Zero Cross
Single Cyc
Burst fire
Ph Angle
Burst StrtR
PA SoftS
Delay Trig
Half Cycle
DEFAULT: Burst Fire
Description
Value
1
2
3
4
19
20
35
10
3
Default
8 0 to 999.9
100
(0 to 25,5
(10 sec)
0 0 to 1024
1
60
0 to 12,75
(3 sec)
31
User's manual
Modbus
Default
Address
3 18
Modbus
Range Unit
Address
n° 20
0 to 255
23
sec)
n° 25
1 to 255 ° 22
0 to 255
24
sec)
Par.
Type
Read
Write
Par.
Type
Read
Write
Read
Write
Read
Write
Read
Write
Read
Write
