Chapter 3 Getting Started

3.1.

Unpacking the OSL2IR

Check that you received all items mentioned on the packing list below.
Item
OSL2IR Light Source
OSL2FB Fiber Bundle
Fiber Bundle Adapter
User Guide
Location-Specific Power Cord
3.2.

Setup Overview

3.2.1.

Electrical Power Supply

1. Turn off the power to the OSL2IR before making any connections.
2. Do not connect the AC power cord to the local power supply until the
connections are completed to the OSL2IR.
3. Be sure to make the connections firmly.
4. Be sure that the OSL2IR operating voltage matches the "local" power
supply.
3.2.2.

Fiber Bundle and Light Output Port

The included OSL2FB fiber bundle can be connected to the OSL2IR light source
for easy control and placement of the illumination. Additionally, the fiber bundle
adapter can be removed from the output port of the OSL2IR. Unscrew the fiber
bundle adapter to expose the internal SM1 (1.035"-40) threads. This threaded
output port can be used for a variety of free space applications. See Section 4.1
for details on the location of the output port and operating controls of the OSL2IR.
Rev A, March 30, 2021
OSL2IR Packing List
1 (Ships Installed in the OSL2IR Output Port)
Chapter 3: Getting Started
Quantity
1
1
1
1
Page 3
