Front panel LEDs and connectors

Front panel LEDs and connectors

LEDs

6
• 2 USB connectors.
• Mounting hardware.
• LED status indicators.
The FortiGate-5005FA2 module comes supplied with fiber and copper SFP
transceivers. You can order the SFP transceivers in any combination. Before you
can connect any FortiGate-5005FA2 front panel interfaces, you must insert the
SFP transceivers into the FortiGate-5005FA2 front panel cage slots.
From the FortiGate-5005FA2 font panel you can view the status of the front panel
LEDs to verify that the module is functioning normally. You also connect the
FortiGate-5005FA2 module to your network through the front panel ethernet
connectors. The front panel also includes the RJ-45 console port for connecting to
the FortiOS CLI and two USB ports. The USB ports can be used with a Fortinet
USB key. For information about using the FortiUSB key, see the
Series Firmware and FortiUSB
Table 1 lists and describes the FortiGate-5005FA2 module LEDs.
Table 1: FortiGate-5005FA2 module LEDs
LED State
Fabric ACT 2 Amber
LINK 2 Green
ACT 1 Amber
LINK 1 Green
Base ACT 2 Amber
LINK 2 Green
ACT 1 Amber
LINK 1 Green
OOS Off
(Out of
Red
Service)
ACC Off or
Flashing
green
STATUS Amber
FortiGate-5005FA2 security system
Guide.
Description
Network activity at backplane fabric interface 2.
Backplane fabric interface 2 is connected at 1000 Mbps.
Network activity at backplane fabric interface 1.
Backplane fabric interface 1 is connected at 1000 Mbps.
Network activity at backplane base interface 2 (backplane2).
Backplane base interface 2 (backplane2) is connected at
1000 Mbps.
Network activity at backplane base interface 1 (backplane1).
Backplane base interface 1 (backplane1) is connected at
1000 Mbps.
Normal operation.
A fault condition exists and the FortiGate-5005FA2 blade is
out of service (OOS). This LED may also flash very briefly
during normal startup.
The ACC LED flashes green when the FortiGate-5005FA2
module accesses the FortiOS flash disk. The FortiOS flash
disk stores the current FortiOS firmware build and
configuration files. The system accesses the flash disk when
starting up, during a firmware upgrade, or when an
administrator is using the CLI or GUI to change the FortiOS
configuration. Under normal operating conditions this LED
flashes occasionally, but is mostly off.
The FortiGate-5005FA2 module is powered on.
