Front panel LEDs and connectors

LEDs

34
Figure 10: FortiSwitch-5003 front panel
Power LED
Management CONSOLE
100Base-TX RJ-45
Ethernet Serial
Extraction
Out of
Lever
base backplane interfaces
Service LED
Mounting
Knot
Table 11 lists and describes the FortiSwitch-5003 module front panel LEDs.
Table 11: FortiSwitch-5003 module front panel LEDs and switches
LED State Description
Off Normal operation.
Red Out of service. The LED turns on if the FortiSwitch-5003
module fails. The LED may also flash briefly when the module
is powering on.
Green The FortiSwitch-5003 module is powered on and operating
normally.
Yellow Caution status. Caution status is indicated by the fault condition
of the CLOCK, OK or INT FLT LEDs.
Off The module is not connected to power.
System Off Normal operation.
Yellow or Link status of out of band management interfaces (not used).
E0, E1
Green
ZRE 0-15 Green Link/Activity mode: Blinking to indicate network traffic on this
interface.
(ZRE
interface that each represents.
network
Link/Speed mode: 100 Mbps connection.
activity
LEDs, LED Yellow Link/Activity mode: The interface is disabled and cannot
forward packets. (not used)
Mode
Link/Speed mode: 1000 Mbps connection.
switch
changes
Off Link/Activity mode: No link.
mode)
Link/Speed mode: 10 Mbps connection.
LED Mode Change the ZRE network activity LED display mode. Normally the ZRE
network activity LEDs operate in Link/Activity mode. In this mode the LEDs
switch
flash green to indicate a link and to indicate network traffic.
Press this button to switch the ZRE LEDs to Link/Speed mode. In
Link/Speed mode the ZRE LEDs use a solid color to indicate a link. The
color of the LED indicates the speed of the link.
CLK Flashing Initialization completed successfully.
Green
OK Green Initialization completed successfully.
ZRE Network
Activity LEDs
(ZRE 0 to 15)
ZRE0 ZRE1 ZRE2
10/100/1000Base-T
Ethernet
Table 12 on page 35 lists the ZRE LEDs and the
FortiGate-5000 Series Introduction
FortiSwitch-5003 module
LED Mode Switch
Reset
Switch
Hot
Extraction
Swap
Lever
LED
Mounting
Knot
01-30003-0378-20061207
