Connectors

Base backplane gigabit interfaces

FortiGate-5000 Series Introduction
01-30003-0378-20061207
Table 8 lists and describes the FortiGate-5001SX connectors.
Table 8: FortiGate-5001SX connectors
Connector Type Speed
1, 2, 3, 4 LC 1000Base-SX Ethernet
SFP
5, 6, 7, 8 RJ-45 10/100/1000
Base-T
CONSOLE DB-9 9600 bps
USB USB
The FortiGate-5001SX port9 and port10 base backplane gigabit interfaces can be
used for HA heartbeat communication between FortiGate-5001SX modules
installed in the same or in different FortiGate-5000 chassis. You can also
configure FortiGate-5001SX modules to use the base backplane interfaces for
data communication between FortiGate modules. To support base backplane
communications your FortiGate-5140 or 5050 chassis must include one or more
FortiSwitch-5003 modules. FortiSwitch-5003 modules are installed in chassis
slots 1 and 2.
For information about base backplane communication see the
Base Backplane Communication
FortiSwitch-5003 module, see the
Protocol Description
Four gigabit SFP interfaces that can
accept fiber or copper gigabit
transceivers. These interfaces only
operate at 1000Mbps.
Ethernet Copper gigabit connection to
10/100/1000Base-T copper networks.
RS-232 serial Serial connection to the command line
interface.
FortiUSB key firmware updates and
configuration backup (FortiOS v3.0).
Guide. For information about the
FortiSwitch-5003 Guide.
Base backplane gigabit interfaces
FortiGate-5000
