Physical description of the FortiGate-5140 chassis

Physical description of the FortiGate-5140 chassis
14
The back panel also includes the back cable tray, an ESD socket and the chassis
ground connector. The ground connector must be connected to Data Center
ground. Use the back cable tray for securing and managing DC power, RTN, and
ground wires.
The back panel also contains 14 backplane slots, which are numbered to
correspond to the front panel slots. The backplane slots are used by some
FortiGate-5000 series modules for various functions. When the FortiGate-5140
chassis is shipped, these slots are covered by backplane slot fillers.
The FortiGate-5140 chassis is a 12U chassis that can be installed in a standard
19-inch rack. Table 2 describes the physical characteristics of the FortiGate-5140
chassis.
Table 2: FortiGate-5140 chassis physical description
Dimensions 21 x 19 x 20.6 in. (53.3 x 48.3 x 52.4 cm)
(Height x Width x Depth)
Shipping weight 110 lb. (50 kg)
completely assembled
with packaging
Operating environment Temperature: 32 to 104°F (5 to 45°C)
Relative humidity: 5 to 85% (Non-condensing)
Storage environment Temperature: -13 to 158°F (-25 to 70°C)
Relative humidity: 5 to 85% (Non-condensing)
Power consumption Maximum: 2,980W DC
Power input 2x redundant -37VDC to -72VDC, 30A per power feed (total 4
+ 4 power feeds)
