Introduction

FortiGate-5005FA2 module

FortiGate-5001SX module

FortiGate-5001FA2 module

FortiSwitch-5003 module

Warnings and cautions

!
FortiGate-5000 Series Introduction
01-30003-0378-20061207
The FortiGate-5005FA2 module is
an independent high-performance
FortiGate security system with
eight Gigabit ethernet interfaces. The FortiGate
end features including 802.1Q VLANs and multiple virtual domains. Two of the
FortiGate-5005FA2 interfaces (port7 and port8) include Fortinet technology to
accelerate small packet performance. For details about the FortiGate-5005FA2
module, see "FortiGate-5005FA2 security system" on page
The FortiGate-5001SX module is
an independent high-performance
FortiGate security system with
eight Gigabit ethernet interfaces. The FortiGate
end features including 802.1Q VLANs and multiple virtual domains. For details
about the FortiGate-5001SX module, see
page 25.
The FortiGate-5001FA2 module is
an independent high-performance
FortiGate security system with
eight Gigabit ethernet interfaces. The FortiGate-5001FA2 module is similar to the
FortiGate-5001SX module except that two of the FortiGate-5001FA2 interfaces
include Fortinet technology to accelerate small packet performance. For details
about the FortiGate-5001FA2 module, see
on page 29.
The FortiSwitch-5003 module
provides base backplane
communication between
FortiGate security modules installed in FortiGate-5140 or FortiGate-5050 chassis.
Base backplane communication can be used for HA heartbeat communication
and for data communication. The FortiSwitch-5003 module can also provide HA
heartbeat and data communication between chassis. The FortiSwitch-5003
module is only used in FortiGate-5140 and FortiGate-5050 chassis. For details
about the FortiSwitch-5003 module, see
Only trained and qualified personnel should be allowed to install or maintain
FortiGate-5000 series equipment. Read and comply with all warnings, cautions
and notices in this document.
Caution: You should be aware of the following cautions and warnings before installing
FortiGate-5000 series hardware.
ACT USB USB
LINK
1 2 3 4 5
ACT
LINK
CONSOLE
OOS ACC STATUS
5005FA2 module supports high-
-
21.
USB
CONSOLE 1 2 3 4
PWR ACC
5001SX module supports high-
-
"FortiGate-5001SX security system" on
USB
1 2 3 4
CONSOLE
PWR ACC
"FortiGate-5001FA2 security system"
"FortiSwitch-5003 module" on page
Warnings and cautions
7 8
6
IPM
5 6 7 8
STA IPM
5 6 7 8
STA IPM
33.
7
