1.2. Quick Start Process

Step
1 Identify the Enclosure Type, Model Type and ratings of
your drive from the model code on the label. In particular
- Check the voltage rating suits the incoming supply
- Check the output current capacity meets or exceeds the
full load current for the intended motor
2 Unpack and check the drive. Notify the supplier and
shipper immediately of any damage.
3 Ensure correct ambient and environmental conditions for
the drive are met by the proposed mounting location.
4 Install the drive in a suitable cabinet (IP20 Units) ensuring
suitable cooling air is available.
5 Select the correct power and motor cables according
to local wiring regulations or code, noting the maximum
permissible sizes
6 If the supply type is IT or corner grounded, disconnect the
EMC filter before connecting the supply.
7 Check the supply cable and motor cable for faults or short
circuits.
8 Route the cables.
9 Check that the intended motor is suitable for use, noting
any precautions recommended by the supplier or
manufacturer.
10 Check the motor terminal box for correct Star or Delta
configuration where applicable.
1 1 Ensure wiring protection is providing, by installing a
suitable circuit breaker or fuses in the incoming supply line.
12 Connect the power cables, especially ensuring the
protective earth connection is made.
13 Connect the control cables as required for the application. 4.6. Control Terminal Wiring
14 Thoroughly check the installation and wiring.
15 Commission the drive parameters.
www.invertekdrives.com
Action See section
2. 1 . Identifying the Drive by Model Number
9. 1 . Environmental
3. 1 . General
3.3. Mechanical Dimensions and Mounting – IP20
Open Units
3.4. Guidelines for Enclosure Mounting
9.2. Rating Tables
9.5. EMC Filter Disconnect
4.9. EMC Compliant Installation
4.5. Motor Terminal Box Connections
4.3.2. Fuse / Circuit Breaker Selection
9.2. Rating Tables
4. 1 . Connection Diagram
4.2. Protective Earth (PE) Connection
4.3. Incoming Power Connection
4.4. Motor Connection
4.9. EMC Compliant Installation
7. Analog and Digital Input Macro Configurations
7.2. Example Connection Diagrams
5. 1 . Managing the Keypad
6. Parameters
Version 1.00 | Optidrive ODE-3 User Guide | 5
Page
7
34
9
9
10
34
36
15
13
1
12
34
1 1
1 1
12
12
13
15
27
27
16
18
