8.4. Modbus Register Map
Register
Par. Type
Number
1 - R/W
2 - R/W
4 - R/W
6 - R
7 R
8 R
1 1 - R
20 P00-01 R
21 P00-02 R
22 P00-03 R
23 P00-08 R
24 P00-09 R
All user configurable parameters are accessible as Holding Registers, and can be Read from or Written to using the appropriate Modbus
command. The Register number for each parameter P-04 to P-60 is defined as 128 + Parameter number, e.g. for parameter P-15, the register
number is 128 + 15 = 143. Internal scaling is used on some parameters, for further details please contact your Invertek Drives Sales Partner.
www.invertekdrives.com
Supported
Function
Function Codes
03 06 16 Low Byte High Byte
Drive Control Command
✔ ✔ ✔
Modbus Speed
✔ ✔ ✔
reference setpoint
Acceleration and
✔ ✔ ✔
Deceleration Time
Error code Drive status
✔
Output Motor Frequency 0..20000 Output frequency in Hz x10, e.g. 100 = 10.0Hz
✔
Output Motor Current
✔
Digital input status
✔
Analog Input 1 value
✔
Analog Input 2 value
✔
Speed Reference Value
✔
DC bus voltage
✔
Drive temperature
✔
Range Explanation
0..3 16 Bit Word.
Bit 0: Low = Stop, High = Run Enable
Bit 1: Low = Decel Ramp 1 (P-04),
High = Decel Ramp 2 (P-24)
Bit 2: Low = No Function, High = Fault Reset
Bit 3: Low – No Function, High = Coast Stop Request
0..5000 Setpoint frequency x10, e.g. 100 = 10.0Hz
0..60000 Ramp time in seconds x 100, e.g. 250 = 2.5 seconds
Low Byte = Drive Error Code, see section 10. 1 . Fault
Code Messages
High Byte = Drive Status as follows:
0: Drive Stopped
1: Drive Running
2: Drive Tripped
0..480 Output Motor Current in Amps x10, e.g. 10 = 1.0 Amps
0.. 1 5 Indicates the status of the 4 digital inputs
Lowest Bit = 1 Input 1
0.. 1 000 Analog input % of full scale x10, e.g. 1000 = 100%
0.. 1 000 Analog input % of full scale x10, e.g. 1000 = 100%
0.. 1 000 Displays the setpoint frequency x10, e.g. 100 = 10.0Hz
0.. 1 000 DC Bus Voltage in Volts
0.. 1 00 Drive heatsink temperature in °C
