Appendix A: Technical Specifications
Camera
Camera Hardware Profile
Camera Housing
Image Features
Video Compression
Video Resolution
External Device Interfaces
Network
Network Protocols
Security
D-Link DCS-4605EV User Manual

Technical Specifications

• 1/2.9" 5 Megapixel progressive CMOS sensor
• 20 meter IR illumination distance
• Minimum illumination:
• 0.01 lux / F2.0 (color)
• 0.008 lux /F2.0 (B/W)
• 0 lux / F2.0 (IR-LED on)
• Built-in Infrared-Cut Removable (ICR) Filter module
• 10x digital zoom
• Minimum object distance 0.5M
• IP66 compliant weatherproof housing
• Configurable image size, quality, frame rate, and bit rate
• Configurable motion detection windows
• Configurable privacy mask zones
• Configurable shutter speed, brightness, saturation, contrast, sharpness and 3D
filter.
• Simultaneous H.265/H.264/MJPEG format compression
• H.265/H.264/MJPEG multicast streaming
• 16:9 - 2560 x 1440 up to 15 fps, 1920 x 1080, 1280 x 720,
800 x 448, 640 x 360 up to 30 fps
• 10/100 BASE-TX Fast Ethernet port
• IPv6
• IPv4
• ARP
• TCP/IP
• UDP
• ICMP
• DHCP client
• NTP client (D-Link)
• DNS client
• DDNS client (D-Link)
• SMTP client
• FTP client
• Administrator and user group protection
• Password authentication
• Focal length: 2.8 mm
• Aperture: F2.0
• Angle of view(4:3):
• (H) 87°
• (V) 65°
• (D) 110°
• Adjustment angle (non-motorized):
• Vertical: 30~90°
• Horizontal: -120~120°
• IK10 vandal-proof housing
• Auto White Balance (AWB)
• Auto Gain Control (AGC)
• Wide Dynamic Range (WDR)
• Time stamp and text overlays
• JPEG for still images
• 4:3 - 2560x1920 up to 15 fps, 1600 x 1200, 1440 x 1080, 1280 x 960, 800 x 600, 640
x 480 up to 30 fp
• Supports 802.3af PoE Class 3
• HTTP/HTTPS
• Samba client
• PPPoE
• UPnP port forwarding
• RTP/RTSP/RTCP
• IP filtering
• Multicast
• CoS
• QoS/DSCP
• SNMP
• 802.1x port-based authentication
• ONVIF-compliant
• HTTP and RTSP authentication
