PRODUCT INTERFACES
③
4-Wire Interface
Input Independence: 10KΩ
PIN1: NULL
PIN2: NULL
PIN3: AUDIO OUT+
PIN4: AUDIO IN+
PIN5: AUDIO IN-
PIN6: AUDIO OUT-
PIN7: GND
PIN8: GND
④
2-Wire Interface
PIN1: GND
PIN2: POWER
PIN3: AUDIO
⑤
POE/PWR Interface
PIN1: -POWER
PIN2: -POWER
PIN3: +POWER
PIN4: +POWER
PIN5: +POWER
PIN6: +POWER
PIN7: -POWER
PIN8: -POWER
5
