Hollyland SOLIDCOM M1 User Manual page 22

PRODUCT INSTALLATION
④
Cascade Two Sets of Devices
1.Through the dedicated-level Ethernet cable in the accessories, Two Sets of
stations can be cascaded, and the number of beltpacks can be expanded up to 16
Beltpacks. When Cascading, One of the Master Device beeds to set as Slave
Device. If set Master Device to Slave Device when used alone, the beltpack will not
be able to talk and the device needs to be reset as Master Device.
2.When cascading, the beltpack number of the Slave Device will automatically
change to 9-16.
3.When the Master Device uses the POE adapter to supply power, the POE adapter
needs to connect to the Power Interface of the Master Station. When cascading,
the Ethernet cable needs to connect to the POE Interface of the Master Device and
the Power Interface of the Slave Device, which can realize the power supply to the
Slave Device without Battery. It is available when the POE Adapter is not used but
NP-F Type Battery for power supply.
20
