X V M E - 6 8 2 Manual
October , 1989
B e f o r e a c c e s s i n g t h e W i n d o w i n thi s m o d e , t h e u p p e r 8 V M E b u s a d d r e s s bi t s m u s t b e sent to
regi s t e r VMEHIADD. Thi s d e f i n e s w h i c h 6 4 k byt e bl o ck of t h e s t a n d a r d V M E b u s address
s p a c e will be a c c e s s e d . Subsequent a c c e s s e s to the wi n dow will use the 8 bits in
V M E H I _ _ _ A D D a n d the l o wer 16 bi t s of the C P U ' s a d d r e s s to form the 24 bit VMEbus
address.
F o r e x a m p l e , to read w o r d 1 2 3 4 5 6 H in the V M E b u s s t a n d a r d a d d r e s s s p a c e , configure the
w i n d o w for V M E b u s s t a n d a r d a d d r e s s s p a c e , output 1 2 H to output port VME_HI_ADD
( a d d r e s s 34H), a n d do a word read at a d d r e s s 0 E 3 4 5 6 H . The w o r d ret u rned will b e from
V M E b u s a d d r e s s 123456H.
6 . 4 . 3 VMEbus I A CK SPACE
W h e n t h e W i n d o w i s conf i g ured for t h e V M E b u s I A CK s p a c e , a byt e r e a d from t h e Window
wi l l c a u s e t h e X V M E - 6 8 2 to p e r f o r m a V M E b u s I A C K cycl e . T h e d a t a ret u rned f r om t h e byte
r e a d will b e the st a t u s ID vect o r ret u rned from the r e s p o n d i n g i n terrupter . S e e Section 6.5
Interrupts.
T h e V M E b u s i n terrupt l e vel a c k n o w l e d g e d d e p e n d s on the w i n d o w a d d r e s s read per the
following:
W I N D O W ADDRESS V M E B U S I N TERRUPT LEVEL
0E0003
0E0005
0E0007
0E0009
OE000B
OE000D
OE000F

6 . 4 . 4 EPROM

W h e n t h e W i n d o w i s conf i g ured f o r E P R O M , t h e l o wer 6 4 K b y t e s of t h e E P R O M will appear
i n the W i n d o w . Thi s i s t h e m o d e s e l e c t e d after reset . Thi s m o d e i s c o m p a t i b l e wi t h t h e IBM
P C / A T architecture.
6-9
1
2
3
4
5
6
7
