X V M E - 6 8 2 Manual
October , 1989
3 . 5 . 3 The F e a t u r e C o n n e c t o r a n d V i d e o Jacks
T h e X V M E - 6 8 2 c o n t a i n s a n E G A F e a t u r e C o n n e c t o r a s part of t h e m o d u l e . T abl e 3 - 5 describes
t h e pi n out s of P 4 , t h e 3 2 -pi n feature connector.
T a b l e 3 - 5 Feat u re Connector
PIN SIGNAL
1 GND
3 N/C
5 J19
7 RSOUT
9 ATRS/L
11 GOUT
13 RS
15 R
17 FEAT I
19 FEATO
21 FCO
23 BS/V
25
VIN
27 INTERNL* 28
29 VOUT
31 GND
T h e r e are al s o t w o vi d eo j a cks l a bel l e d P 5 a n d P 6 . These a r e s t a n d a r d vi d eo j a cks that are
avai l a bl e for u s e o n t h e X V M E - 6 8 2 . Currentl y , t h ey a r e not c o n n e c t e d to t h e ci r cui t ry o n the
c a r d i t sel f . The u s e r c a n d e s i g n a d a u g h t e r to c o n n e c t to t h e f e at u re c o n n e c t o r that woul d use
t h e s e t w o j a cks a s outputs.
3-9
PIN SIGNAL
2 N/C
4 J18
6 GSOUT
8 BSOUT
10 BOUT
12 G
14 B
16 ROUT
18 BLANK
20 FC1
22 GS/I
24 HIN
26 O S C 4 M h z clk)
E X T OSC
30 HOUT
32 + 5 VDC
