5 . 3 ROM R E S I D E N T S E T U P ROUTINE
S E T U P i s a p r o g r a m whi c h r e s i d e s i n the R O M B I O S P l u s E P R O M S o n the XVME-682 CPU
m o d u l e . It i s u s e d to wri t e confi g urati o n i n f o rmat i o n i n to bat t e ry- b a c k e d memory.
S E T U P s t o r e s t h e fol l o wi n g i n formati o n i n CMOS:
• Date a n d Time
• Diskette a n d H a r d di s k types
• Keyboard opt i o ns (i n stal l e d or not installed)
• Monitor type
• Processor speed
• Math c o p r o c e s s o r opt i o n (not accessible)
• Base memory size
• Extended memory size
5 . 3 . 1 When to U s e SETUP
S E T U P m u s t b e run by t h e u s e r when:
• installing t h e s y s t e m for t h e first time
• changing dri v es or moni t or type
• changing s y s t e m f e at u res (i . e. C P U speed)
• replacing t h e battery
5 . 3 . 2 Invoking t h e S E T U P Routine
T o i n voke the R O M resi d ent S E T U P routi n e o n the X V M E - 6 8 2 si m pl y d e p r e s s the "CTRL",
"AL T", a n d " S " k e y s s i m u l t a n e o u s l y o n a P C / A T keyboard.
Y o u m a y scrol l t h r o u g h t h e avai l a bl e S E T U P opt i o ns by u s i n g t h e u p - a r r o w a n d down-arrow
k e y s o n the P C / A T k e y b o a r d . Sel e ct i o ns c a n b e modi f i e d b y mani p -ul a t i n g the ri g ht-arrow
a n d left- a r r o w k e y s . M e m o r y si z e p a r a m e t e r s are e n t e r e d vi a t h e n u m b e r keypad.
