Exchange of Battery:

DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED
BATTERIES ACCORDING TO THE MANUFACTURERS
INSTRUCTIONS.
Felaktigt batteribyte kan medfora fara for explosion. Anvand darfor endast
samma typ eller likvardig typ enligt apparattillverkarens rekommendation.
Kassera forbrukade batterier enligt tillverkarens anvisning
Lithiumbatteri. Eksplosionsfare ved fejlagtig håndtering. Må kun udskiftes med
batteri af samme fabrikat og type.
Lever det brugte batteri tilbage til leverandøren.
Recommended battery type: CR2032.
TC stock no. (TCcode) for battery: 342 0000 11
__________________________________________________________________________________________________________________________________________________________________________________________________
TC Electronic A/S
CAUTION:
VARNING:
ADVARSEL:
Exchange procedure
1. Turn Off Power and Disconnect Power Cord.
2. Loosen 5 screws, see fig. 1, and remove the top cover.
3. Desolder the old battery by warming up each terminal one by one. Avoid
any short circuit of the terminals. Be careful not to damage the wiring on
the board.
4. Insert new battery and solder the terminals one by one. Avoid any short
circuit of the terminals.
5. The voltage measured directly across the terminals of the new battery
should be higher than 3.0VDC.
6. Do not discard the old battery. Hand it over to a recycling company or your
dealer.
Finalizer Service manual page 9
