ADD THE FINAL PUNCH TO YOUR MIX
ADD THE FINAL PUNCH TO YOUR MIX
The internal auto-sensing Analog balanced I/O.
power supply automatically
accepts and adjusts itself
to 100-240V, 50/60Hz.
T E C H N I C A L S P E C I F I C A T I O N S :
DIGITAL INPUTS AND OUTPUTS
Connectors: XLR (AES/EBU) RCA Phono (S/PDIF)
Optical (Toslink)
Formats: AES/EBU (24 bit), S/PDIF (20 bit), EIAJ CP-340,
IEC 958, EIAJ Optical (Toslink)
Output Dither: HPF TPDF dither 16, 20 and 24 bit
Sample Rates: 44.1 kHz, 48 kHz
Processing Delay: 0.2 ms @ 48 kHz
Frequency Response DIO: DC to 23,9 kHz ± 0,01 dB @ 48 kHz
Compressor THD+N: -122 dB (0,00008%) @ 10 dB Compression,
20 Hz to 20 kHz
ANALOG INPUTS
Connectors: XLR balanced (pin 2 hot)
Impedance: 20 kohm
Max. Input Level: +22 dBu (balanced)
Min. Input Level (for 0 dBFS): -10 dBu
Sensitivity: @ 12 dB headroom: -22 dBu to +10 dBu
A to D Conversion: 24 bit (1 bit, 128 times oversampling)
A to D Delay: 0.8 ms @ 48 kHz
Dynamic Range: >103 dB (unweighted), >106 dB(A)
THD: -95 dB (0,0018 %) @ 1 kHz, -6 dBFS (FS @ +16 dBu)
Frequency Response: 10 Hz to 20 kHz: +0/-0.2 dB
Crosstalk: <-80 dB, 10 Hz to 20 kHz typical Ð100 dB @ 1 kHz
ANALOG OUTPUTS
Connectors: XLR balanced (pin 2 hot)
Impedance: 100 ohm (active transformer)
Max. Output Level: +22 dBu (balanced)
Full Scale Output Range: -10 dBu to +22 dBu
D to A Conversion: 24 bit (1 bit, 128 times oversampling)
D to A Delay: 0.57 ms @ 48 kHz
Dynamic Range: >100 dB (unweighted), >104 dB(A)
THD: -86 dB (0.005 %) @ 1 kHz, -6 dBFS (FS @ +16 dBu)
Frequency Response: 10 Hz to 20 kHz: +0/-0.5 dB
Crosstalk: <-60 dB, 10 Hz to 20 kHz
typical Ð90 dB @ 1 kHz
T C E L E C T R O N I C A / S , S I N D A L S V E J 3 4 , D K - 8 2 4 0 R I S S K O V, D E N M A R K á P H O N E : + 4 5 8 6 2 1 7 5 9 9 á F A X : + 4 5 8 6 2 1 7 5 9 8
E M A I L : I N F O @ T C E L E C T R O N I C . C O M á H T T P : / / W W W . T C E L E C T R O N I C . C O M
TC ELECTRONIC INC., 790-H HAMPSHIRE ROAD, WESTLAKE VILLAGE, CA 91361, USA á PHONE: (805) 373 1828 á FAX: (805) 379 2648
Optional Digital
Master Fader
connection.
The MIDI section in the
Finalizer is very useful
for controlling fades
from a sequencer.
EMC
Complies with: EN 55103-1 and EN 55103-2, FCC part 15, Class B,
CISPR 22, Class B
SAFETY
Certified to: IEC 65, EN 60065, UL 1419 and CSA E65
ENVIRONMENT
Operating Temperature: 32¡ F to 122¡ F (0¡ C to 50¡ C)
Storage Temperature: -22¡ F to 167¡ F (-30¡ C to 70¡ C)
Humidity: Max. 90 % non-condensing
PCMCIA INTERFACE
Connector: PC Card, 68 pin type 1 cards
Standards: PCMCIA 2.0, JEIDA 4.0
Card Format: Supports up to 2 MB SRAM
CONTROL INTERFACE
MIDI: In/Out/Thru: 5 Pin DIN
GPI, Pedal, Fader: Phone jack, 0 ohm to 50 kohm
GENERAL
Finish: Anodized aluminum front
Plated and painted steel chassis
Dimensions 19Ó x 1.75Ó x 8.2Ó (483 x 44 x 208 mm)
Weight: 5.2 lb. (2.35 kg)
Mains Voltage: 100 to 240 VAC, 50 to 60 Hz (auto-select)
Power Consumption: < 20 W
Backup Battery Life: > 10 years
Note: Due to continuous development and standardization all specifications
are subject to change without notice
OPTIONAL DIGITAL MASTER FADER AVAILABLE
THINK FAST
THINK FAST
DELIVER THE HEAVYWEIGHT MASTERING PUNCH
DELIVER THE HEAVYWEIGHT MASTERING PUNCH
Introducing
Introducing
Finalizerª Express
Finalizerª Express
The Finalizer Express is the fast and efficient
way to turn your mix into a Professional Master!
Based upon TC's Multi-Award winning Finalizer
Mastering Technology, it delivers the finishing
touches of clarity, warmth and punch to your
mixes, putting the world of professional maste-
ring within your reach...
