Power On Sequence:
The table below shows the Power On Sequence for main board version PC12001-3, when the Finalizer is switched on by using the power switch at the back panel. Equal sequence
numbers mean that the events are independent of each other. Column Trouble Shooting has hints about what to check if the event fails.
The Power On Sequence is also made as flow chart, see appendix.
No
Event
1a
SB_VCC (POWER_SB, Violet wire) goes to approx. 5VDC and supplies IC44.
1b
+15V (POWER_+15V, Orange wire) goes to approx. +15VDC.
1c
-15V (POWER_-15V, Yellow wire) goes negative to approx. -15VDC.
2
TP5 goes to +4.7VDC. C149 is discharged and keeps IC44 pin 13 low and
subsequently IC44 pin 8 goes high.
3a
+5VSB, (+5V_STANDBY*, Brown wire) goes to approx. +3.2VDC
3b
Q10 and Q11 turns on IC47
4a
+5V (POWER +5V, Red wire) goes high.
4b
TP1, +15V starts up.
4c
TP2, -15V starts up.
5a
Display backlight turns on
5b
TP12, power for PLL goes high.
5c
TP9, CPU clock starts up, 14.112MHz
5d
TP13, 256FS starts up
5e
TP3, +5VAD starts up.
5f
TP4, -5VAD starts up.
6a
TP10, DSP clock starts up, 44.100KHz
6b
TP14, ADA_64FS starts up
6c
TP15, ADA_1FS starts up
6d
LD4 and LD5 flashes and stays on. Often the intensity of LD5 is a little higher
than the intensity of LD4.
__________________________________________________________________________________________________________________________________________________________________________________________________
TC Electronic A/S
Trouble shooting
Power cord, DZ1, IC44 or power supply.
power supply, load (normal current load is approx. 70mA)
power supply, load (normal current load is approx. 70mA)
IC44, DZ1
R213
Q10, Q11, IC47
power supply, load (normal current load is approx. 0.6A)
IC47
IC47
Ribbon cable at Front connector J2, two solderings at display for back light.
IC24, IC27
IC26 + soldering
IC28, IC26 + soldering, If CPU clock is missing the frequency is undefined.
IC11, Q8
IC11, Q9
IC25 + soldering
IC25 + soldering
IC25 + soldering
The intensity depends on the in/output level settings. Oscillation in analog section gives
constant high intensity. If so, check C172, C173, C174, C175,
Finalizer Service manual
page 13
