Appendix list: Flow chart, Schematics, Part lists, PCB Lay-out

The list below show the contents and the order of appendix.
Flow chart for Power On Sequence
Schematic for Main board ver. PC12001-3
Part list for Main board ver. PC12001-3
PCB lay-out for Main board ver. PC12001-3
Schematic for Front boards ver. PC12502-2
Part list for Front boards ver. PC12502-2
Schematic for Front boards ver. PC12502-3
Part list for Front boards ver. PC12502-3
PCB lay-out for Front boards ver. PC12502-2 &
PC12502-3
Part list for mechanical parts in Finalizer
__________________________________________________________________________________________________________________________________________________________________________________________________
TC Electronic A/S
2 pages
14 pages
13 pages
1 page
3 pages
6 pages
3 pages
6 pages
1 page
2 pages
Finalizer Service manual page 21
