Inverter Status To Display Fault Condition - Go Power GP-ISW-200 User Manual

Green
Orange
Red

4.4.2 INVERTER STATUS TO DISPLAY FAULT CONDITION

LED status
Green
Red
Red Blink
Red Fast Blink
Orange
Orange Fast Blink
Orange Slow Blink
11.5 ~ 15.0V
15.0 ~ 15.5V
>15.5V
Status
Normal
Over Current Protection /
Over Load Protection
(AC output short-circuit
and over load)
Under Voltage Protection
(Input DC voltage under
spec)
Over Voltage Protection
(Input DC voltage over spec)
Device startup process
abnormal
Under Temperature
Protection
(Heat sink temp. under
-20°C)
Over Temperature
Protection
(Heat sink temp. over
80°C)
OPERATION
23.0 ~ 30.0V
30.0 ~ 31.0V
>31.0V
Recovery point
12.5V @ DC12V system
25V @ DC24V system
14.5V @ DC12V
29V @ DC24V system
-
> 0°C
(heat sink temperature)
< 60°C
(heat sink temperature)
gpelectric.com | [page 27]
