Operation; Final Inspection - Go Power GP-ISW-200 User Manual

Shut down over
voltage
Fan alarm
GP-ISW-400 LED signal
 SE400 LED signal
Status
Status
Normal or
12
Power ON
Over load
Over temp. /
Under temp.
(Heat sink temp. over
80℃ or under -20℃)
Over current /
Over load
(AC output short-circuit
and over load)
Over voltage
(Input DC voltage over
spec.)
Under voltage
(Input DC voltage
under spec.)
3-1-3. AC Output 

4.1 FINAL INSPECTION

1. Verify all cables / conduit runs are secured with zip ties or other non-conductive cable
clamps to prevent damage from vibration.
2. Ensure all cables that pass through walls, bulkheads or any other openings are protected
against abrasion by using strain reliefs and/or grommets.
3. Check all AC, DC and ground connections are securely tightened, and if required covered
with suitable anti-seizing grease.
4. Check all connections are secure in the main and sub panels - replace all covers.
5. If required by code, have the installation inspected by an electrical inspector.
Table 7. GP200 & GP350 LED status
LED Signal
LED Signal
Green
Orange
Red
Table 8. GP400 LED status
LED flashes red light every 0.1
seconds, then inverter shut
down.

OPERATION

LED flashes red light slowly
once and quickly twice every
1.6 seconds
Description
Description
LED lights in solid green
LED fast blink with two long
beeps
LED slow blink
LED lights in solid red with one
short beeps
LED fast blink
LED slow blink with one long
beeps &two short beeps
gpelectric.com | [page 25]
