88 5543 101
Bermuda
Entertainment Credenza
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 pc.
E.
Base
1 pc.
H.
Plinth
1 pc.
Hardware List
Cam Lock Screw
19 pcs.(+1 extra)
Cam Lock
19 pcs.(+4 extra)
For assembly see instructions in carton 88 5543 102
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
Wood Screw
for Back Panel
12 pcs.(+1 extra)
Adjustable Pin
24 pcs.(+1 extra)
servicedesk@homestyles-furniture.com
Magnet
2 pcs.
Wood Screw
for Magnet
4 pcs.(+1 extra)
Tools recommended for assembly :Level
F.
Shelf
4 pcs.
I.
Back Panel
2 pcs.
J.
Back Panel
1 pc.
Pull Handle
2 pcs.
Machine Screw
2 pcs.
