88 5543 26
Upholstered Bench
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.

Part List

A.
Cushion
1 pc.
B.
Top
1 pc.
F.
Base
1 pc.
G.
Back Panel
1 pc.

Hardware List

Magnet
2 pcs.
Tools required for assembly :
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
M3x15
Wood Screw
4 pcs.(+1 extra)
Phillips screwdriver
C.
D.
Side Panel
Side Panel
1 pc.
1 pc.
H.
Leg
4 pcs.
J.
Door
1 pc.
M4x32
Machine Screw
2 pcs.
Tools recommended for assembly :
E.
Middle Panel
1 pc.
I.
Leg
1 pc.
K.
Door
1 pc.
Pull Handle
2 pcs.
Level
