- Page 1 D/N WDR 700TVL FAST DOME CAMERA SP9364/9368 N/P D/N WDR 700TVL FAST DOME IP CAMERA IPS9364/9368 N/P D/N HUMAN TRACKING FAST DOME CAMERA ST9364/9368 N/P INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
CONTENTS Pages Preface Features Warnings & Cautions Structural Element Fast Dome Camera Set Up Alarm Out Mode Switch Setting RS-485 Protocol Switch Setting Fast Dome ID Address Setting Refer Chart Fast Dome Connection Jack and Cable Requirement Installation ... - Page 3 Display the Camera Setting Menu Auto Focus Setting Zoom Speed Setting Focus Speed Setting ...
-
Page 4: Preface
Fast Dome series are fully-functional and user-friendly. It will meet your need for a wide range of surveillance applications. The application for LILIN tracking dome are (1) Access control area (Bank Chest, Military Magazine, Oil or Chemical tank...). (2) After hour monitoring area (Warehouse, Archives, Parking exit...). -
Page 5: Features
FEATURES 36X Auto Focus Lens Build-in 36X optical zoom lens with focal length 3.3~119mm 700 Horizontal TV lines Automatic / Manual Iris Control Preset ID / Name Preset Background Environment File Private Mask ° 360 continuous rotation Up to 128 programmable preset positions Preset positions auto scanning °... - Page 6 Human Tracking Fast Dome Camera Function (ST9364/9368 series) ： 1. Human Tracking Fast Dome Camera series are smart sensor and built-in intelligent video processing which has surveillance applications on, (1) Moving object detection. (2) Tracking and zooming moving object. ...
-
Page 7: Warnings & Cautions
WARNINGS & CAUTIONS Please read the manual before attempting installation or operation 1. Please be aware to the warnings and cautions notice. 2. Don't use any chemical detergent to clean the machine surface, use a damp cotton cloth only. Regularly clean the dome cover to assure proper focus ability. 3. -
Page 8: Structural Element
STRUCTURAL ELEMENT Dome Cover RS-485 In/Out Terminal Camera Case Video Out Jack Bottom Chassis Alarm In/Out connector Power In Jack (AC100 ~ 240V) RJ45 Network Connector [IPS9364/9368] Power In Jack (AC24V) -
Page 9: Fast Dome Camera Set Up
FAST DOME CAMERA SET UP DIP Switch Setting Camera ID Switch RS-485 Protocol Switch Alarm Out Mode Switch Alarm Out Mode Switch Setting Alarm Out Mode can be set as NC (normally close) or NO (normally open) RS-485 Protocol Switch Setting ... - Page 10 PROTOCOL2 (MLP2) for detail of command format. RS-485 Protocol DIP Switch of LILIN D/N WDR 700TVL Fast Dome (IP) Camera / D/N Human Tracking Fast Dome Camera Series Setting RS-485 Protocol DIP Switch Setting...
-
Page 11: Fast Dome Id Address Setting Refer Chart
Up to 64 Fast Dome Camera can be serial linking in one system. Therefore each dome is addressing by ID switch located at the base of the Fast Dome. When select MLP1 (MERIT LILIN PROTOCOL 1), Camera ID setting as followings: 1 2 3 4 5 1 2 3 4 5... - Page 12 When select MLP2 (MERIT LILIN PROTOCOL 2), Camera ID setting as followings:...
- Page 14 8 9 0 8 9 0 8 9 0 8 9 0...
-
Page 15: Fast Dome Connection Jack And Cable Requirement
Fast Dome Connection Jack and Cable Requirement AC100~240V Power Cable AC24V Power Cable RS-485 Twisted Pair Cable To Keyboard or Matrix . ..etc. Video Signal Cable To Monitor Alarm In/Out Cable To PIR CAT5 Network Cable 1. AC100 ~ 240V Power Cable 2. - Page 16 b. Prepare the individual conductors for clamping. After clamping the contacts, push them into the proper holes in the accessory connector of this camera until they snap in place. Contact CAUTIONS : CONNECT THIS TO 24V AC CLASS 2 POWER SUPPLY ONLY. 3.
-
Page 17: Installation
INSTALLATION Indoor Installation Structural Drawing Embedded Mounting Attached Mounting... -
Page 18: Embedded Mounting (False Ceiling)
Embedded Mounting (False Ceiling) Step 1 Ceiling Preparation Drill a 3/32" (2.4mm) hole at the center of the Use a pencil and a compasses to mark a circle 6.7" chosen area. (170mm) in diameter and cut the circle. Step 2 The Ceiling Ring 200mm 93mm Attach the ring to... - Page 19 Step 4 Attach the Camera Body and Base Attach camera body to Turn camera body Tighten the two screws base counter clockwise to to fix the camera body Notice: tight position position connector is correct or not. Step 5 The Fix Ring Put on the three L shape Attach fix ring with Tighten the three black...
-
Page 20: Attached Mounting (Fixed Ceiling)
Turn the ring clockwise Attach dome cover to Turn the dome cover to tight position camera body clockwise to tight position Note : After dome cover is attached, use glass-cleaning cloth to clean dome cover. Unclean dome cover may affect camera performance. Attached Mounting (Fixed Ceiling) Step 1 Fix The Base Turn the dome cover... - Page 21 Step 2 Camera Setting Setting Fast Dome ID, Alarm Out Mode, RS-485 Protocol Step 3 Attach the Camera Body and Base Attach camera body to Turn camera body Tighten the two screws base counter clockwise to to fix the camera body Notice: tight position position connector is...
-
Page 22: Wall Mounting (Fixed Bracket)
Wall Mounting (Fixed Bracket) Step 1 Fix The Bracket Fix bracket first, and Turn the dome cover Separate the dome Untighten the two pull control cable and counter clockwise cover from camera screws from base power cable from bracket cable outlet. Turn the camera cover Separate the camera Set all of control... - Page 23 Step 4 Camera Setting Setting Fast Dome ID, Alarm Out Mode, RS-485 Protocol Step 5 Attach the Camera Body and Base Attach camera body to Turn camera body Tighten the two screws base counter clockwise to to fix the camera body Notice: tight position position connector is...
-
Page 24: System Configuration
SYSTEM CONFIGURATION LILIN's integrated Fast Dome Surveillance System is suitable for a wide range of surveillance applications. The system can be as single fast dome with one keyboard or encompassing as 64 domes with comprehensive matrix switching, PC control and even Digital Video Recording. - Page 25 Multiple Domes means that more than one fast dome is linked in the system. Each dome connects to next dome forming a serial linking. Each dome has an individual ID dip switch, which allows the keyboard to identify each fast dome and make command. Sometimes it is more convenient to wire a telemetry system in star configuration rather than daisy chain.
-
Page 26: Fast Dome, Matrix And Keyboard
Fast Dome, Matrix and Keyboard Matrix System is designed to process multiple video systems and video switching. Its central process unit (CPU) can manage multiple video signals simultaneously and control other linking system, such as fast dome or PIH-820 Ⅲ telemetry receiver. -
Page 27: Fast Dome With Pc Control
9600 bps). The PC control port RS-232 is converted to RS-485 format by interface. User may use their own software (protocol) or software provided by LILIN to control the dome. In this system up to 64 fast domes can be linked. -
Page 28: Fast Dome, Dvr And Keyboard
Fast Dome, DVR and Keyboard The DVR System is an advanced digital recording product, with long recording time and easy searching features. Telemetry remote control is twisted pair for data transmission to the fast dome. Fast Dome can be controlled directly from the control panel of the DVR, or from keyboard. Each DVR (Digital Video Recorder) can manage 16 video signals and via RS-485 ot daisy connection 16 sets of fast dome camera. -
Page 29: Fast Dome Ip Camera With Pc Control
Fast Dome IP Camera with PC Control The Fast Dome IP Camera can be connected via RJ-45 Ethernet cable that provides both Internet and/ or Intranet access. Multiple Fast Dome IP Cameras can be connected with in a Hub or multiple Hubs. Please consult your network administrator for network architecture and software settings. -
Page 30: Operation
OPERATION Initial Power Up Inspection After the power is first applied to a dome it will perform a self-test procedure. This calibrates and checks the basic functions of the dome, control is not possible during this self-test period. Once the camera has stopped moving, it will then be ready to control. If preset positions and tours have been programmed into a dome and the power is turned off, the dome will enter the Auto Scan mode once the power is turned on again (after self-test period). -
Page 31: Fast Dome Selection
Fast Dome Selection To call out a dome controlling or setting To select 1st Fast Dome ALARM LENS ICR C.ESC MATRIX WIPER SPRAY LIGHT RESET Push key followed by key. C.SET 。 SEARCH PRESET CTRL1 CTRL2 ... -
Page 32: Iris Control
Iris Control The purpose of iris control is to adjust brightness on target. It can be set as Auto Iris or Manual Iris. 1. Iris Open Push key, to open the iris and brighten the picture. LENS ICR C.ESC ALARM MATRIX... - Page 33 Joystick Control Move the Joystick to bring the camera to the desired view position. Adjusting Lens ZOOM IN / OUT, FOCUS NEAR / FAR / AUTO and IRIS O / C / AUTO keys. When set up preset point, using manual focus will LENS ...
-
Page 34: Recalling Preset Positions
Recalling Preset Positions Once the required preset positions have been stored in a dome, they may be quickly recalled, returning the dome to exact position. To recall 1st Preset Position: Push key followed by key. -
Page 35: Activating Auto Pan
Activating Auto Pan When the Auto Pan function is activated, the fast dome will auto touring the preset groups entered. To activate Auto Pan: ALARM LENS ICR C.ESC MATRIX AUTO Push key, confirming the activation of autopan. WIPER SPRAY LIGHT... -
Page 36: Alarm Management
Alarm Management The 6 alarm inputs of each fast dome are corresponding with the first 6 preset positions. When 。 an alarm signal is triggered, the dome will go to the relevant position at 360 /sec. Make sure the first 6 preset positions are set to desired alarm areas. Alarm input can be set to NC (normally close) or NO (normally open) depends on alarm detector. -
Page 37: Setup Menu Tree
SETUP MENU TREE SETUP LANGUAGE ENGLISH MENU DISPLAY PRESET ID SETUP ZOOM RATIO ALARM MESSAGE TIME DATE/TIME DATE DATE FORMAT PAN/TILT ANGLE AUTO PAN AREA TITLE DOME CAMERA AUTO FOCUS AUTO SETTINGS ONE PUSH ZOOM SPEED FOCUS SPEED AUTO IRIS LEVEL HIGH LUM. - Page 38 SELF RETURN MODE AUTO EDIT POSITION AUTO MODE DWELL TIME PRESETS PRESET NUMBER SCAN SPEED PATROL LEARN PRESET MAP EDIT POSITION CLEAR EDIT ID SCENE FILES EXPOSURE MODE DWELL TIME WHITE BALANCE SPEED CLR PRESET TOURS NUMBER EDIT TOUR CLEAR ABOVE NUMBER DWELL TIME SPEED PRIVACY...
-
Page 39: Fast Dome Camera Function Setup
Fast Dome Camera Function Setup SP9364/9368 & IPS9364/9368 & ST9364/9368 (build-in 36X optical zoom lens) series provide on-screen display (OSD) setup menu, all functions can be selected and set via OSD Setup Menu. Setup Menu Display Press key on the keyboard to recall Setup Menu. -
Page 40: Display System Information
2. Camera, Pan/Tilt, Receiver version 3. Font of OSD version 4. Protocol rate and format 5. Fast dome ID number 6. Protocol version, LILIN717 (LILIN MLP1), LILIN MLP2 Display Character Setup Menu 1. Display Character Setup Menu Press ... - Page 41 3. Zoom Ratio Setting Push joystick down to select <ZOOM RATIO>, and then push joystick left or right to make selection: OFF : No Zoom Ratio on the monitor screen. ON : Zoom Ratio on the monitor screen. 5~30 sec : Display elapsed time. Zoom Ratio will have been displayed on the monitor screen ...
- Page 42 (3) Date Format Setting Push joystick down to select <DATE FORMAT>, and then push joystick left or right to adjust format of date. yy / mm / dd mm / dd / yy dd / mm / yy →...
- Page 43 USER AREA AREA NUMBER <EDIT POSITION> <EDIT TITLE> CLR AREA ABOVE NUM BACK EXIT 1. Push joystick down to select <AREA NUMBER>, and then push joystick left or right to select area number. (1~6) 2. Push joystick down to select <EDIT POSITION>, and then press ...
-
Page 44: Display Dome Function Setup Menu
(3) Modify Area title Push joystick down to select <EDIT AREA> on the area title setting, and push joystick right to select modifiable characters. Push joystick down to select new characters, and press key to chose. -
Page 45: Camera Setting Menu Display
Camera Setting Menu Display 1. Display the Camera Setting Menu After getting in dome setting menu, push joystick down to select <CAMERA>, and then press C.SET key into camera setting menu. CTRL1 CAMERA AUTO FOCUS AUTO ZOOM SPEED FOCUS SPEED MID. -
Page 46: Shutter/Agc Setting
AUTO SETUP ADVANCED SETTING SHUTTER/AGC <MANUAL> SHUT HIGH LUM. MODE WHITE BAL <ATW> BRIGHTNESS <HLC> LOW LUM MODE DAY/NIGHT AUTO 25dB GAIN NIGHT ENV. NORMAL SHUT ---- SYNC BRIGHTNESS x0.50 <IMAGE> BACK EXIT BACK EXIT... - Page 47 BRIGHTNESS: > Push joystick down to select <BRIGHTNESS , and then push joystick left or right to adjust brightness level of darker part. x0.25 x0.50 x0.75 x1.00 → → → 1 3 BLC Setting: ...
-
Page 48: White Balance Setting
Push joystick down to select <AGC>, and then push joystick left or right to make selection. 10dB 20dB 25dB 30dB → → → 2 2 WDR+SHUT Mode: ... - Page 49 1 2 DELAY CNT: Push joystick down to select <DELAY CNT>, and then push joystick left or right to make selection. ATW delay time ranges are 0 ~ 255 (short ~ long).
-
Page 50: Hlc (High Light Compensation) Setting
Push joystick down to select <R-GAIN>, and then USER2 WB push joystick left or right to adjust white balance to R-GAIN lower color temperature, and push joystick down to B-GAIN ... -
Page 51: Night Environment Setting
AUTO: When light level is over 10 lux, camera switches DAY automatically to produce color image. When light drops below 5 lux, camera switches NIGHT automatically to produce monochrome image. -
Page 52: Image Setting
(7) Image Setting After getting in advanced setting menu, push joystick down to select <IMAGE>, and then press C.SET key into image setting menu. CTRL1 ADVANCED SETTING IMAGE-1 SHUTTER/AGC <MANUAL>... -
Page 53: Pan/Tilt Setting Menu
IMAGE-1 IMAGE-2 DIGITAL EFFECT 3D-NR CONTRAST E-ZOOM SHARPNESS R-GAIN B-GAIN <NEXT> BACK EXIT BACK EXIT NR (3D Noise Reduction): Push joystick down to select <3D-NR>, and then push joystick left or right to select ... -
Page 54: Self Return Time Setting
OFF: NO action. 1 ~ 128: Home positions are preset position from fast dome. Note: When keyboard control isn't used, "Return Mode" is set for "HOME" and "Return Time" is over, "Return Mode" function will be started. 3. Self Return Time Setting Push joystick down to select <SELF RETURN TIME>, and then push joystick left or right to select return time: 3sec... -
Page 55: Auto Scan Mode Setting
Note: 1. Press AUTO key on the keyboard to perform Auto mode function. 2. On tracking mode, once the object move out the traceable or discriminable area, the fast dome camera will back to the preset 1 to continue doing tracking function after ... -
Page 56: Preset Function Setting Menu
(1) Patrol Learn Setting Push joystick down to select <LEARN>, and then press key into setting menu. C.SET CTRL1 Control joystick or press lens control key to start patrol learn mode. (Count down time ... - Page 57 PRESET POSITION PRESETS PRESET NUMBER <PRESET MAP> <EDIT POSITION> <EDIT ID> SCENE FILES DWELL TIME 0 sec SPEED 255 deg/sec <33-64> <65-96> <97-128> CLR PRESET ABOVE NUM. BACK EXIT BACK EXIT 3. Preset Position Setting Push joystick down to select <EDIT POSITION>, and then press ...
- Page 58 (3) Modify Preset ID Push joystick down to select <EDIT AREA> on the preset ID setting, and push joystick right to select modifiable characters. Push joystick down to select new characters, and press key to chose.
-
Page 59: Tour Function Setting Menu
Tour Function Setting Menu 1. Display the Tour Setting Menu After getting in dome setting menu, push joystick down to select <TOURS>, and then press key into tours setting menu. C.SET CTRL1 2. Tour Number Selection TOURS Push joystick down to select <NUMBER>, and then push NUMBER joystick left or right to select Tour1 or 2. -
Page 60: Privacy Zones Setting Menu
Privacy Zones Setting Menu 1. Display the Privacy Zones Setting Menu After getting in dome setting menu, push joystick down to select <PRIVACY ZONES>, and then press key into privacy zones setting menu. C.SET CTRL1 PRIVACY ZONES NUMBER MODE <EDIT ZONE>... -
Page 61: Alarms Setting Menu
Alarms Setting Menu 1. Display the Alarms Setting Menu After getting in dome setting menu, push joystick down to select <ALARMS>, and then press key into alarms setting. C.SET CTRL1 ALARMS POSI 1 POSI 2 POSI 3 POSI 4 POSI 5 POSI 6... -
Page 62: Password Function Menu (Ip Camera Not Support)
4. Alarm Output Control Setting Push joystick down to select <OUT>, and then push joystick left or right to select alarm output mode: IN 1 IN 2 IN 3 IN 4 IN 5 IN 6 → → → → → →... - Page 63 Push joystick down to select <OK>, and then press key to confirm and back to password C.SET CTRL1 function menu, or push joystick down to select <CANCEL>, and then press key to cancel C.SET CTRL1 password. These numbers of Edit column will be reset to "1111". Note: When edit password setting and camera recording function are simultaneously performed, ...
-
Page 64: Restore Factory Defaults
Restore Factory Defaults 1. Display the Restore Function Initialization Menu After getting in dome setting menu, push joystick down to select <FACTORY INITIAL>, and then press key into factory initial setting. C.SET CTRL1 RESTORE FACTORY DEFAULTS RESTORE BACK EXIT 2. -
Page 65: Schedule Setup Menu
C.SET CTRL1 Push joystick down to select <SCHEDULE SETUP>, and then press key into schedule C.SET CTRL1 setting. MERIT LILIN FAST DOME SCHEDULE SETUP LANGUAGE ENGLISH <ALARM IN> <DISPLAY SETUP> <STARTUP AUTO OPTIONS> <DOME SETTINGS>... -
Page 66: Startup Auto Options Menu
4. End Time Setting Push joystick down to select <END>, and then press key into time setting. Then push C.SET CTRL1 joystick left or right to select end time and press key for next item. C.SET CTRL1 → ... -
Page 67: Daylight Saving Time Menu
Example: 1. 12:00, perform SEQ. Mode 2. 13:00, STOP (If "self return mode" is home, "home position setting" is 1, and "self return time" is 10 min, camera will be performed "self return mode" function and recall ... -
Page 68: Specification
SPECIFICATION Operational ° ° Manual Pan / Tilt Speed 0.15 ~ 120 /sec (8 stages) Preset Position Pan / Tilt Speed ° ° 1 ~ 255 /sec Preset Position Dwell Time 1 ~ 255 sec Recall Preset Position Pan / Tilt Speed °... -
Page 69: Optical Lens
Zoom In / Out Manual Control Zoom In / Out Accuracy Electrical Power Supply 24VAC or 100VAC ~ 240VAC (Option) Power Consumption 13W [SP9364/9368] 16W [IPS 9364/9368 15W [ST 9364/9368 Control Interface RS-485 (1 Input / 1 Output) RS-485 Voltage 5.6V... -
Page 70: Appendix A Quick Reference Table
APPENDIX A Quick Reference Table Function Operation To Tilt Up Push Joystick Forward To Tilt Down Push Joystick Down Pan / Tilt Control To Pan Left Push Joystick Left Push Joystick Right To Pan Right Dome Selection Numeric Key + CAM Zoom In ZOOM IN Zoom Out... -
Page 71: Appendix B Trouble Shooting
APPENDIX B Trouble Shooting 1. No Power 1-1. Check power input connection 1-2. Check connection between camera body and upper base (AC24V Model) 2. No Video 2-1. Check camera video output on camera 2-2. Check cable (damaged cable) 2-3. Check video input connection on monitor 2-4. - Page 72 MERIT LILIN ENT. CO., LTD http://www.meritlilin.com 66-SP936CSE...
