UNISTRUT CEILING MOUNTS
VDM-CA-4X4-BK
THANK YOU
Thank you for purchasing the VDM-CA-4X4-BK or VDM-CA-8X8-BK unistrut ceiling mount.
Please read these instructions thoroughly before installing or assembling these products.
PRODUCT FEATURES
• Accepts 1 1/2" NPSM couplings and pipe extensions
• 300 lb. weight capacity
Instruction Sheet
VDM-CA-4X4-BK
AND
VDM-CA-8X8-BK
VDM-CA-8X8-BK
I-00840
Rev -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Middle Atlantic Products VDM-CA-4X4-BK
Summary of Contents for Middle Atlantic Products VDM-CA-4X4-BK
- Page 1 UNISTRUT CEILING MOUNTS VDM-CA-8X8-BK VDM-CA-4X4-BK THANK YOU Thank you for purchasing the VDM-CA-4X4-BK or VDM-CA-8X8-BK unistrut ceiling mount. Please read these instructions thoroughly before installing or assembling these products. PRODUCT FEATURES • Accepts 1 1/2” NPSM couplings and pipe extensions •...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS • Read these instructions. • Heed all warnings. • Clean only with dry cloth. • Keep these instructions. • Follow all instructions. • Only use attachments/accessories specified by the manufacturer. DANGER HAZARDOUS VOLTAGE: The lightning flash with the WARNING: A warning alerts you to a situation that could result arrowhead symbol, within an equilateral triangle is intended to alert the in serious personal injury or death.
- Page 3 WEIGHT RATINGS Model Product Weight Weight Rating VDM-CA-4X4-BK 0.79 lbs. (0.36 kg) 300 lbs. (136.1 kg) Maximum Total Rated Load VDM-CA-8X8-BK 3.02 lbs. (1.37 kg) 300 lbs. (136.1 kg) Maximum Total Rated Load SUPPLIED COMPONENTS AND HARDWARE (VDM-CA-4X4-BK) (VDM-CA-8X8-BK) (4x)
- Page 4 4X4 UNISTRUT INSTALLATION 1. Insert (4x) unistrut nuts (B) in (2x) pre-hung unistrut channels (not supplied) spaced 2 3/4” apart by pressing nut into channel groove lengthwise, and then turning 90° to seat nut into channel. (FIGURE A) 2. Align unistrut nuts (B) with mounting slots in unistrut mount (A). 3.
- Page 5 8X8 UNISTRUT INSTALLATION 1. Insert (4x) unistrut nuts (B) in (2x) pre-hung unistrut channels (not supplied) spaced 4” or 6” apart by pressing nut into channel groove lengthwise, and then turning 90˚ to seat nut into channel. (FIGURE B) 2. Align unistrut nuts (B) with mounting slots in unistrut mount (A). 3.
- Page 6 - customerservicecanada@middleatlantic.ca Factory Distribution USA: NJ - CA - IL Canada: ON - BC At Middle Atlantic Products we are always listening. Your comments are welcome. Middle Atlantic Products is an ISO 9001 and ISO 14001 Registered Company. Page 6...
