Instruction Sheet
VSA Series
Telescoping Rackshelf
THANK YOU
Thank you for purchasing the VSA Series Telescoping Rackshelf. Please read these instructions
thoroughly before installing or assembling this product.
PRODUCT FEATURES
• Shelf area telescopes to reach from front to rear rackrail.
• Can mount upside down for an increased usable width.
I-00236
Rev E
