Omcan MS-IT-0300-G Instruction Manual page 19

Model MS-IT-0300-G
Item No. Description
19776 Spring 14x1.5x60 for 13641
17381 Spring 22 5x1 8x18 for 13641
19250 Spring 24.8x1.8x15 for 13641
19248 Spring 15.6x20x2.2 for 13641
78283 Screw for 13641
20263 Motor 120V/60Hz-1 for 13641
19791 Oiler Oil Cap with Screw for 13641
17390 Rubber Shock ABS. 16x22x2.5 for 13641
17392 PL.Shock Absorb.8.5x20 for 13641
36761 Shock Absorber for 13641
36762 Rubber Plug for 13641
16955 Shock Absorber for 13641
17395 Shock Absorber for 13641
17402 Deflector HM-HP for 13641
27888 Ring Deflector for 13641
36766 Knife Guard for 13641
77616 Strain Relief for 13641
17415 Strain Relief for 13641
60421 Electrical Conduit for 13641
36778 Wire-Press for 13641
36779 Core-Hitch+Nut for 13641
19811 Pin Sharpener for 13641
16959 Pin Grinding for 13641
17419 Pin Truing for 13641
17422 Pin Deflector for 13641
Pivot Hinged Support O10x22 (Pin Grind-
17423
ing Long) for 13641
78237 Knife Shaft for 13641
23649 Knife Shaft for 13641
17426 Assy Honing Stone Pivot for 13641
17427 Assy Grinding Stone & Pin for 13641
23645 Sharpener Pivot for 13641
26126 Table for 13641
19831 Gauge Plate Flat Bar VS for 13641
16960 Support Plate for 13641
36830 Flat Bar C for 13641
16961 Foot for 13641
78235 End Grip for 13641
17443 End Grip for 13641
13641
Position Item No. Description
M7032 17444 Stud Carriage for 13641
M7052 AI228 Stud Motor Cover for 13641
M7071 60424 Touch Pad Screw for 13641
M7120 AI229 Protection Switch Lev.(ETL) for 13641
M7132 78282 Lock Washer for 13641
M8246 24030 Sharpener Operating Handle for 13641
O4040 78284 Bracket for 13641
P1019 65640 Oil Receiver for 13641
P1034 19657 Washer 4 for 13641
P103401 19659 Washer 8 for 13641
P1053 17454 Washer for 13641
P1059 78258 Washer 30.5x46.5x0.6 for 13641
P1081 36880 Washer U6592 3 for 13641
P1130 17455 Washer U6592 4 for 13641
P1165 17456 Washer U6592 5 for 13641
P1532 20422 Washer for 13641
P2004 16967 Washer U65926 for 13641
Washer U6592 6 Stainless Steel for
P2008 17457
13641
Washer U6592 8 Stainless Steel for
P2011 36884
13641
Washer U6592 10 Stainless Steel for
P2014 36885
13641
P2015 17458 Contact Washer for 13641
P3205 36889 Washer 10.5x16x1 for 13641
P3225 16969 Washer 18.2x25x0.5 for 13641
P322601 17460 Washer 34.2x46x0.5 for 13641
P3269 19674 Washer 44.5x51.5x0.2 for 13641
P3289 19675 Washer C for 13641
P3323 36892 Washer 17x30x4 for 13641
Stainless Steel Special Washer 8.5x24x2
P3378 36893
for 13641
P3380 78261 Rotor Stator H.50 for 13641
P3381 77619 P.C.B. Protection Box for 13641
P3528 AI230 Electric Box for 13641
P4328 19680 Ball 3 17 for 13641
P4621 17465 Ball 4.76 for 13641
P4756 41350 P.C. Board 120V/60 ETL for 13641
P4765 36908 Track C-CD for 13641
P5008 17475 Pin 8x42 for 13641
P6729 19867 Pin D10 M6 L26 for 13641
P7018 17476 Foot Support Pin D.10 M8 L.37 for 13641
Parts Breakdown
Position Item No.
P7431 19870
P7437 36934
P7447 19871
P7939 78236
P8620 36952
P8625 60422
P8626 19878
R1027 19879
R6003 19880
R6006 AI231
R6204 19883
R6251 77628
R6504 16978
R6505 19887
R6508 16983
R6509 36999
R6512 79283
R6512X 37005
R6520X 37013
R6530X 37017
R6806 17492
R6816 26127
R6840 37021
R6846 37023
R6848 19691
R6863 19692
R6874 23648
R6897X 37030
R8021 37031
S100480 37033
S1006 19697
S3005 19699
S3015 19702
S3265 37042
S3815 37047
S7583 19706
S7594 37048
S7595 77629
19
Description Position
Stator 120/60 for 13641 S8562
Bracket.Tray C for 13641 S8802
Bracket Sharpener for 13641 S8809
Bracket Washer C for 13641 S8951A
Magnet Support for 13641 S8991
Touch Pad Back Casing for 13641 S9236
Rubber Cap for 13641 T1002
Label for 13641 T1603
Label for 13641 T1606
Label Plate for 13641 T1617A
Label Oil for 13641 T1690
Switch Overlay H-C (CE) for 13641 T1760
Blade Cover Fastener Assy C for 13641 T5006
Blade Cover Fastener C for 13641 T5036
Knife Shaft Assy for 13641 T8026
Riding Pin (Diam.28) for 13641 T8538
Shaft Pin for 13641 T9742
Gauge Plate for 13641 V3033
Motor Fan MEC80 148x16 for 13641 V4014
Screw STTC U6113 M4x30 for 13641 V6009
Screw STTC U6113 M6x40 for 13641 V6013
Stud C Model for 13641 V602115
Screw for 13641 V6030
Screw STEI U5929 M5x5 for 13641 V6065
Grub Screw M6x6 for 13641 V6066
Screw M6x8 for 13641 V6067
Screw for 13641 V6073
Screw M12x16 U5927 for 13641 V6081
Screw STEI U5929 M8x16 for 13641 V6083
Screw TC U6107 M4x8 for 13641 V6206
Screw M5x16 for 13641 V6211
Screw M4x25 for 13641 V6231
Screw M6x25 for 13641 V6246
Screw TCEI U5931 M8x25 for 13641 V6254
Screw TC AUT.D7971 2.9x13 for 13641 V6276
Screw for 13641 V6278
Screw TCTC AUT.D7981 3.5x9.5 for
V6279
13641
Screw TBTC AUT.U6954 4.2x13 for
V6296
13641
