Parts Breakdown
Model MS-IT-0300-G
Item No. Description
Sharpening Assy (Support & Stones)
17272
for 13641
16902 Ring EL.Benzing 8 for 13641
17281 Ring EL.Seeger Ext.25 for 13641
Ring EL.Seeger EST.25 Ser.Heavy for
77585
13641
19484 Ring 52 for 13641
19612 Ring 33 for 13641
17283 Oil Seal 25x52x10 for 13641
17285 Oil Seal 60x75x8 for 13641
19493 Oil Seal 25x47x07 for 13641
77601 Oil Seal OR 2010 for 13641
17287 O-Ring 123 17.86x2.62 for 13641
17288 O-Ring 3081 20.24x2.62 for 13641
77602 O-Ring OR 4500 for 13641
36547 Carriage Rod lg.465 for 13641
36549 Shock Absorber Rod 12x185 for 13641
36552 Carriage Rod for 13641
19501 Meat Grip Rod A310 & C for 13641
78270 Body for 13641
17298 Bushing Fastener C for 13641
16904 Bushing Sharpener for 13641
16905 Bushing DU 16x18x15 for 13641
17304 Bushing for 13641
17305 Bushing DU 18x20x15 for 13641
16906 Bush Sharpening for 13641
16907 Bush. Sharpening for 13641
17307 Bushing Sharp. for 13641
19630 Bushing Fastener HBC for 13641
78265 Bushing Funnel for 13641
18648 Bushing for 13641
Bushing to Hold Carriage Springs for
36566
13641
17313 Bushing DU 14x15x16 for 13641
23646 Sharpener Pivot Ferrule for 13641
41601 Bushing DU 6x8x10 for 13641
Bushing Fastener Guard Knife C for
78677
13641
16909 Sharpener Cover for 13641
13641
Position Item No. Description
A1003 36590 AG35-C-H Carriage for 13641
A5406 19527 Carriage Ass C for 13641
A5453 77605 Assy Wiring 6 Poles LG.400 for 13641
Cord 0.5 LG.750 Coverblade Microswitch
A5454 65610
for 13641
A5485 17316 Pin 8.5mm for 13641
A5495 17317 Pin .11 for 13641
A5809 36601 Rivet 1.9x5 for 13641
Blade Cover Bolt Keeper 14x14 M for
A5815 36607
13641
A5816 20458 Capacitor 20uF for 13641
A5848 AI225 Connector for 13641
A5852 74403 Connector Faston 2 Poles Male for 13641
A5854 77611 P.C.B. Cover Box for 13641
A5857 AI226 Cover Box for S1006 for 13641
B1085 78266 Front Motor Cover for 13641
B1252 36615 Back Motor Cover for 13641
B1285 36617 Motor Fan Cover for 13641
B1337A 19534 Housing Sharpener H for 13641
B1807 17334 Bearing 2Z-6205 25x52x15 for 13641
B6006 16925 Bearing 2RS-6204 20x47x14 for 13641
B6048 36631 Bearing 2RS-6205 25x52x15 for 13641
B6053 16926 Bearing 2RS-6000 (10x26x8) for 13641
B6056 60423 Touch Pad Gasket for 13641
B6057 19637 Nut M3 for 13641
B6075 19638 Nut M4 for 13641
B6076 77612 Self-Locking Nut M3 UNI7473 for 13641
B6083 16928 Nut U5589 M6 for 13641
B6104B 19639 Nut M8 for 13641
B6110 36637 Nut U5589 M8 Stainless Steel for 13641
B6212 36639 Nut U5721 M5 Stainless Steel for 13641
Domed Nut U5721 M6 Stainless Steel
B6221 36640
for 13641
B6244 19642 Nut M8 for 13641
B6256 36643 Nut U5588 M5 for 13641
B6288 19644 Nut M6 for 13641
B6398 36647 Nut U5588 M8 for 13641
C1603 36648 Nut U5588 M8 for 13641
Position Item No.
C1854 36651
C1901 36661
C3236 30459
C3351 17342
C4601 17345
C4602 36680
C4640 77614
C5007 17348
C5815 17351
C6005 36689
C6010 36697
C644680 17352
C6447 16930
C6463 17356
C6466 16932
C6573 19587
C6807 36705
C8011 36707
C8024 36708
C8056 18220
C8067 62453
C8242 16938
D0101 17369
D0102 36723
D0110 72282
D0133 AI227
D0135 13593
D0135X 36733
D0152X 36734
D0153X 21645
D0155X 21644
D0160 36741
D0163 17377
D0165 17379
D0165X 17380
18
Description Position
Sharpener Support Nut for 13641 D0183
Carriage Shock Absorber Spacer for
D5762
13641
Stop Cam for 13641 E1406
Cam 15mm for 13641 E1420
Cam Bearing for 13641 E1458
Carriage Felt for 13641 F1606
Nylon Cable Tie (Diam.45x200) for
F2815
13641
Flange Knife C for 13641 F6034
Locknut for 13641 G5018
Stainless Steel Locknut M8 for 13641 G5027
Logging Lock Nut GL25 for 13641 G5064
Touch Pad-Start/Stop Push Button for
I1680
13641
Handle C for 13641 I1901A
Fastener Handle for 13641 I1926
Handle Carriage C for 13641 I1936
Sharpener Knob for 13641 I1957A
Adjustment Knob for 13641 I1970A
Switch Handle for 13641 I1980
Assy Index Knob for 13641 I1990A
Knob-Handling for 13641 I203576
Nylon Gear for 13641 I2402
Switch and Knob for 13641 I3611
Switch 4x20 for 13641 I3647
Switch 4x25 for 13641 I3678
Overload Protector for 13641 I3697
Interr.Bipolare A Levetta 16A for 13641 I3709
Blade 300 57x4x254x22 for 13641 L0606
Magnet 8x10 for 13641 M0803
Magnet 12x6 for 13641 M0804
G Stone 51x15x14.3 for 13641 M6602
F Stone 51x7x14.3 for 13641 M6621
Spring 2.9x4x12 Stainless Steel for
M7001
13641
Spring 8.5x1.0x25 Stainless Steel for
M7013
13641
Spring 11.9x0.7x27 Stainless Steel for
M7029
13641
Spring 13.4x1.3x30 Stainless Steel
M7030
for 13641
