D.3.3

Software update Level T, K (Touch screen)

Refer also to D.2 Software Editions for a complete list of the different editions of software available "in the market".
IMPORTANT
The following instructions/illustrations are relative to software 4.3.7. onwards. Previous software editions could
differ to what is reported in this manual edition.
NOTE!
Cooking programs created with the new 4.3.7 and onwards versions are not compatible with older versions software
(4.0.4 - 4.2.2 - 4.2.4).
The software to update an oven is divided in three different packages.
• Programming File
• Programming Parameters
• Pnc and Serial number writing in the ID card only required in case of UI replacement.
DISPLAY
BOARD
ACU-X27
C1.1 C1.2
O/I BUTTON "SM"
D.3.3.1 AGELUX Web site - Example illustration
• Programming File (Software)
• Programming Parameters (Parameters)
PNC 217782 touch oven / GAS
38
USER
BOARD (U.I)
O/I ON OFF
BOARD (SM)
RECOVERY
ACU-X28
USB - J15 OF
USER BOARD (U.I)
IMPORTANT
Recipes created in "Programs" with previous
software versions (4.0.4 - 4.2.2 - 4.2.4) are
recognized by the new software 4.3.7 but you
cannot export a recipe created with 4.3.7 in a
previous software version, in this case the
recipe will not be displayed on the USB which
will appear empty to the old software oven
version. Update the oven with last software
version.
"Programming File" and "Programming Parameters" have to
be both installed in case of software upgrade while "PNC and
Serial" is only required in case of UI replacement.
All packages of software can be downloaded from the official
TechDoc web pages (hereafter illustrations of the packages
appearance in AGELUX/ PRIDE).
