EN User Manual | Oven
EOD6C46K2
EOD6C46X2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EOD6C46K2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Electrolux EOD6C46K2

Summary of Contents for Electrolux EOD6C46K2

  • Page 1 EN User Manual | Oven EOD6C46K2 EOD6C46X2...

  • Page 2: Table Of Contents

    Access your full user manual at electrolux.com/manuals Get usage advice, brochures, trouble shooter, service and repair information at electrolux.com/support For more recipes, hints, troubleshooting download My Electrolux Kitchen app. Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2.
  • Page 3 the use of the appliance in a safe way and understand the hazards involved. Children of less than 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. •...

  • Page 4: Safety Instructions

    • WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. • WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements or the surface of the appliance cavity. •...
  • Page 5 2.2 Electrical connection For the section of the cable refer to the total power on the rating plate. You can also refer to the table: WARNING! Risk of fire and electric shock. Total power (W) Section of the cable (mm²) •...
  • Page 6 – do not put aluminium foil directly on • If you use an oven spray, follow the safety the bottom of cavity of the appliance. instructions on its packaging. – do not put water directly into the hot • Do not clean the catalytic enamel with appliance.

  • Page 7: Installation

    3. INSTALLATION 3.1 Building in WARNING! Refer to Safety chapters. www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG/Electrolux Oven - Column installation (*mm) min. 550 min. 560 (*mm) min. 550 min. 560 ENGLISH...

  • Page 8: Product Description

    3.2 Securing the oven to the cabinet 4. PRODUCT DESCRIPTION 4.1 General overview Control panel Knob for the heating functions Display Control knob Heating element Socket for the food sensor Lamp Cavity embossment Shelf support, removable Shelf positions 4.2 Accessories •...

  • Page 9: Before First Use

    5.2 Control panel overview functions to the off position to turn the appliance off. Select a heating function to turn on the appliance. Turn the knob for the heating Timer Fast Heat Up Light Food Sensor Confirm setting 5.3 Display Display with key functions.

  • Page 10: Daily Use

    6.1 Initial cleaning Before the first use, clean the empty appliance and set the time: 00:00 Set the time. Press 6.2 Initial preheating Preheat the empty oven before the first use. Step 1 Remove all accessories and removable shelf supports from the oven. Step 2 Set the maximum temperature for the function: Let the oven operate for 1 h.
  • Page 11 Steam cooking Preheat the empty oven for 10 min to create hu‐ midity. Put food in the oven. Select the steam Set the tempera‐ Fill the cavity embossment with tap water. heating function. ture. The maximum capacity of the cavity embossment is 250 ml. Do not refill the cavity embossment during cook‐ ing or when the oven is hot.
  • Page 12 Heating function Application This function is designed to save energy during cooking. When you use this function, the temperature in the cavity may differ from the set temperature. The residual heat is used. The heating power may be reduced. For more information refer to "Daily Use" Moist Fan Baking chapter, Notes on: Moist Fan Baking.
  • Page 13 7.5 Assisted Cooking Legend Legend Shelf level. The amount of water for the steam func‐ The display shows P and a number of the tion. dish that you can check in the table. Preheat the appliance before you start cooking. Dish Weight Shelf level / Accessory...
  • Page 14 Dish Weight Shelf level / Accessory Spare Ribs 2 - 3 kg; use raw, 2 3; deep pan - 3 cm thin spare Add liquid to cover the bottom of a dish. Turn the meat af‐ ribs ter half of the cooking time. Lamb leg with bones 1.5 - 2 kg;...

  • Page 15: Clock Functions

    Dish Weight Shelf level / Accessory Loaf cake 2; loaf pan on wire shelf Baked potatoes 1 kg 2; baking tray Put the whole potatoes with skin on baking tray. Wedges 1 kg 3; baking tray lined with baking paper Use your favourite spices.
  • Page 16 Clock Function Application To postpone the start and / or end of cooking. Time Delay Maximum is 23 h 59 min. This function has no effect on the operation of the oven. To turn on and off the Uptimer select: Menu, Settings. Uptimer 8.2 How to set: Clock functions How to set: Time of day...

  • Page 17: Using The Accessories

    How to set: Time Delay Step 1 Step 2 Step 3 Step 4 Step 5 Step 6 The dis‐ play The display shows: the shows: time of day --:-- STOP Select the Press repeat‐ START Set the start Set the end heating Press: Press:...
  • Page 18 9.2 Using Trivet and Grill- / Roasting WARNING! Be careful when you remove the accessories from a hot oven. There is a risk of burns. You can use the trivet to roast larger pieces of meat or poultry on one shelf position. Step 1 Put the trivet into the deep pan so that the supports of the wire shelf point up.

  • Page 19: Additional Functions

    9.4 How to use: Food Sensor Step 1 Turn on the oven. Step 2 Set a heating function and, if necessary, the oven temperature. Step 3 Insert: Food Sensor. Meat, poultry and fish Casserole Insert the tip of Food Sensor into the centre of meat, Insert the tip of Food Sensor exactly in the centre of the fish, in the thickest part if possible.

  • Page 20: Hints And Tips

    This function prevents an accidental change of the appliance function. - press and hold to turn on the - press and hold to turn it off. function. A signal sounds. - flashes when the lock is turned on. 10.2 Automatic switch-off For safety reasons the appliance turns off after some time, if a heating function works (°C)
  • Page 21 (°C) (min) Rolls, 9 pieces baking tray or dripping pan 30 - 40 Pizza, frozen, 0.35 kg wire shelf 10 - 15 Swiss Roll baking tray or dripping pan 25 - 35 Brownie baking tray or dripping pan 25 - 30 Soufflè, 6 pieces ceramic ramekins on wire 25 - 30...
  • Page 22 Ramekins Pizza pan Baking dish Flan base tin Ceramic Dark, non-reflective Dark, non-reflective Dark, non-reflective 8 cm diameter, 5 28 cm diameter 26 cm diameter 28 cm diameter cm height 11.4 Cooking tables for test institutes Information for test institutes Tests according to IEC 60350-1.

  • Page 23: Care And Cleaning

    ( °C) (min) Fatless True Fan Wire shelf 2 and 4 40 - 60 Preheat the oven for sponge Cooking 10 min. cake, cake mould Ø26 Short bread True Fan Baking tray 140 - 150 20 - 40 Cooking Short bread True Fan Baking tray 2 and 4 140 - 150...
  • Page 24 Clean all accessories after each use and let them dry. Use only a microfibre cloth with warm water and a mild detergent. Do not clean the accessories in a dishwasher. Do not clean the non-stick accessories using abrasive cleaner or sharp-edged objects. Accessories 12.2 How to clean: Cavity embossment...
  • Page 25 Clean the oven with catalytic cleaning Before the catalytic cleaning remove all accessories. Step 1 Step 2 Step 3 Select Menu / Cleaning When the cleaning ends the signal When the oven is cold, clean the sounds. The oven turns off. oven floor with a wet soft cloth press three times.
  • Page 26 Step 5 Hold the door trim (B) on the top edge of the door at the two sides and push inwards to re‐ lease the clip seal. Step 6 Pull the door trim to the front to remove it. Step 7 Hold the door glass panels by their top edge and carefully pull them out one by one.

  • Page 27: Troubleshooting

    12.6 How to replace: Lamp Always hold the halogen lamp with a cloth to prevent grease residue from burning on the lamp. WARNING! Risk of electric shock. The lamp can be hot. Before you replace the lamp: Step 1 Step 2 Step 3 Turn off the oven.

  • Page 28: Energy Efficiency

    ......... 14. ENERGY EFFICIENCY 14.1 Product Information and Product Information Sheet according to EU Ecodesign and Energy Labelling Regulations Supplier's name Electrolux EOD6C46K2 949499578 Model identification EOD6C46X2 949499577 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, conventional mode 0.93 kWh/cycle...

  • Page 29: Menu Structure

    Heat source Electricity Volume 72 l Type of oven Built-In Oven EOD6C46K2 32.1 kg Mass EOD6C46X2 31.7 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐ ods for measuring performance.

  • Page 30: Environmental Concerns

    Select the option Adjust the value and from Menu structure - select to enter - press to con‐ Select the setting. the Menu. firm setting. press and press Turn the knob for the heating functions to the off position to exit the Menu. Menu structure Assisted Cooking Cleaning...
  • Page 32 867377009-A-082023...
