C
Hold ON OFF
Relative
Show Info
Configure
ON OFF
Auto Range
Switch Range Select manual range mode, press to switch range

DMM Information Window

The Multimeter Information Window is displayed on the top right of the screen.
9
8
7
Description
1. Manual/Auto range indicators, MANUAL refers to the measuring range in
manual operation mode and AUTO refers to the measuring range in automatic
operation mode.
2. Measurement mode indicators:
A ------ Current measurement
V ------ Voltage measurement
------ Resistance
R
------ Diode measurement
------ Continuity test
------ Capacitance
C
3. Range.
4. Measurement display ("OL" is short for overload, indicates the reading
exceeds the display range)
5. Data hold mode is enabled.
6. Multimeter recorder (See
Multicomp-Pro user Manual
Measuring capacitance
Freeze the display during measurement.
When making relative measurements, reading is
the difference between a stored reference value
and the input signal.
Show/Hide the information window
Select auto range mode
1
Figure 5-3 Multimeter Information Window
t
t
Multimeter Recorder
"
2 3
" on page 98
95
4
5
