3. USB Device port: It is used to transfer data when external USB equipment
connects to the oscilloscope regarded as "slave device". For example: to use
this port when connect PC to the oscilloscope by USB.
4. USB Host port: It is used to transfer data when external USB equipment
connects to the oscilloscope regarded as "host device". For example: Saving
the waveform to USB flash disk needs to use this port.
5. LAN port: the network port which can be used to connect with PC.
6. Connector for the DC power source via an AC-DC adapter
Top Panel
User Interface Introduction
29
28
27
26
25
Figure 3-4 Illustrative Drawing of Display Interfaces
1. Waveform Display Area.
2. Run/Stop (touchable) (see "Use Executive Buttons" on P94)
3. The state of trigger, including:
Auto: Automatic mode and acquire waveform without triggering.
Multicomp-Pro user Manual
Input connectors of multimeter
Figure 3-3 Top Panel
4
1
3
5
2
24
23
22
Input connectors of channels
7
6
5
8
7
9
10
11
12
13
14
15
16
17
18
19
20
21
