multicomp pro MP720644 User Manual page 71

the USB memory device as an OTA file.
Data format description of OTA waveform file
If the source mode is set to Out1 or Out2, OTA file consists of two parts: the file header
and the channel data. If the source mode is set to Out1&Out2, OTA file consists of three
parts: file header, the first channel data, and the second channel data. The file header
represents the parameter of file data, which is expressed in "parameter name + value".
Each parameter name is a case-sensitive string of 4 bytes. The parameter value is at least
4 bytes.
1.Format description of the file header:
1) HEAD
Parameter
name
HEAD
2) TYPE
Parameter
name
TYPE
3) BYTE
Parameter
name
BYTE
4) SIZE
Parameter
name
SIZE
5) VOLT
Parameter
name
VOLT
6) SAMP
Parameter
name
SAMP
Multicomp-Pro user Manual
Meaning
Header size
Meaning
Model
Meaning
Data length in bit
Meaning
File size
Meaning
Voltage division,
divided by 400 is
ADC resolution.
(When the source
mode is
Out1&Out2, it is
the first channel
voltage division.)
Meaning
Sample rate
67
Value Comment
4 bytes int
Value Comment
12 bytes char
Value Comment
4 bytes int
Value Comment
4 bytes int Used to check the file
integrity
Value Comment
4 bytes float The value indicates
voltage (the unit is mV),
such as 200 mV.
Value Comment
4 bytes float The unit is Sa/s.
