OneKEY
IR4 Keys, Chargers & OneKEY Manager
Peel the clear film from the adhesives
1c
on the bottom of the charger (4
adhesives on the 4 position charger
and 6 on the 8 position charger).
Section 1: Charger (4 & 8
1a
Position) Installation
• Adhesive Mount - Use the
povided alcohol wipe to clean the
area where the charger will be
placed. Allow it to dry completely.
Route the cable as determined in
1d
Step 1b, place the charger where
desired and apply pressure for at
least 10 seconds.
Determine how the cable will be
1b
routed. There are 3 exits on the bot-
tom of each charger.
1
2
3
Screw Mount - Drill 2 small pilot
2a
holes based on the distances (either
horizontally or vertically) below that
correspond to your charger.
• 4 Position Charger - 60mm (2
3
/
in).
8
• 8 Position Charger - 130mm (5
1
/
8
Insert the screws (not provided,
choose screws appropriate to the
fixture's material) into the pilot holes.
Allow enough of the screw sticking
out to hang the charger.
60mm (2
/
in)
3
8
130mm (5
/
in)
1
8
The cable can also descend down
1c
through the fixture if a hole or slot is
present.
2b
Place the charger onto the screws.
in).
Advertisement
Related Manuals for inVue OneKEY
Summary of Contents for inVue OneKEY
- Page 1 • Adhesive Mount - Use the OneKEY povided alcohol wipe to clean the IR4 Keys, Chargers & OneKEY Manager area where the charger will be placed. Allow it to dry completely. Peel the clear film from the adhesives Route the cable as determined in Screw Mount - Drill 2 small pilot Place the charger onto the screws.
- Page 2 • Yellow - Return the Key to the Manager the Manager. Plug the power supply There are 2 versions of the OneKEY, here are the differences. within the hour. Battery is low or Timeout is into a power outlet.
- Page 3 Section 3: Enrolling the OneKEY The LED on the back of the OneKEY Plug the network cable into the eth- Select the Language. Confirm by Manager (OKM) in Access Manager will illuminate, indicating that ernet port on the OneKEY Manager.
- Page 4 Code entry in Access Manager. setup. You will then be asked if you are already using an InVue Onekey at your site. Select “No” for a new installation. Select “Yes” To transfer a code from an existing key (See Section 5).
- Page 5 Section 5: Transferring an Select “Yes” to have the OKM create The OKM will then generate a site Select which OneKEY you are using. Existing Site Code a site code. code. You can proceed to section 6. IR4 will be for adding or replacing new OKMs.
- Page 6 When prompted, select “Proceed”. Section 5bii: IR3 Place an IR3 OneKEY with the Place a new IR4 OneKEY onto the Place the coded IR4 OneKEY into the existing store code onto the Programming Station and press the OKM.
- Page 7 OneKEY Section 6. on the OKM. the OKM. If you do not receive this screen, Remove a fully charged OneKEY please contact InVue Customer from the charger. Service for further assistance. The Key will sync with the OKM. If using Access Manger you will be Enter your PIN.
-
Page 8: Touchscreen Care
Return the Key to the charger for the Once synced, this screen will appear. Instructions: next user. • The Key & OneKEY Manager • If the screen becomes dirty, use a contain non-replaceable lithium soft clean cloth to gently wipe the ion batteries. - Page 9 Cet équipement est conforme aux limites d’exposition aux radiations IC CNR-102 établies pour un environnement non contrôlé. SD0718 Rev1 05/19/21 www.invue.com NA / LATAM // 704.752.6513 • 888.55.INVUE EMEA // +31.23.8900150 APAC // +852.3127.6811 © 2021 InVue Security Products Inc. All rights reserved. InVue is a registered trademark of InVue Security Products.
