inVue PL601 Quick Start Manual

Smart Lock
OneKEY Padlock
PL601
Remove the battery pull tab.
4

First Time Usage:

1
Pull the lock shackle from the lock body.
Replace the back cover, aligning the
5
scribe mark with the "unlocked" icon.
2 With the padlock in the unlocked state
turn the back cover counterclockwise to
align the scribe mark to the "unlocked"
icon.
Rotate the back cover so that the
6
scribe mark will align to the "locked"
icon.
3 Remove the back cover from
padlock.

Installation:

7
Rotate the lock shackle out so that it
will fit into the latch.
