CHAPTER 7
Installing the M120 Router Without a
Mechanical Lift

Tools and Parts Required to Install the M120 Router Without a Mechanical Lift

Related
Documentation
Removing Components from the Chassis Before Installing the M120 Router Without
a Mechanical Lift
Copyright © 2010, Juniper Networks, Inc.
All manuals and user guides at all-guides.com
Tools and Parts Required to Install the M120 Router Without a Mechanical
Lift on page 59
Removing Components from the Chassis Before Installing the M120 Router Without a
Mechanical Lift on page 59
Installing the M120 Router Without Using a Mechanical Lift on page 69
Reinstalling Components in the Chassis After Installing the M120 Router Without a
Mechanical Lift on page 71
To install the router, you need the following tools and parts:
Phillips (+) screwdrivers, numbers 1 and 2
3/8-in. nut driver
ESD grounding wrist strap
M120 Router Chassis Description on page 6
M120 Router Installation Summary on page 43
M120 Chassis Lifting Guidelines on page 195
General Safety Warnings for M Series, MX Series, and T Series Routers on page 190
Removing Components from the Chassis Before Installing the M120 Router Without a
Mechanical Lift on page 59
To make the router light enough to install manually, you first remove most components
from the chassis. The procedures in this section for removing components from the
chassis are for initial installation only, and assume that you have not connected power
59
