M120 Multiservice Edge Router Hardware Guide
Table 39: RJ-48 Connector to RJ-48 Connector (Straight) Pinout for the
Router (continued)
RJ-48 Pin (on T1/E1 PIC)
(Data numbering form)
4
5
3
6
7
8
Table 40: RJ-48 Connector to RJ-48 Connector (Crossover) Pinout for
the Router
RJ-48 Pin (on T1/E1 PIC)
(Data numbering form)
1
2
4
5
3
6
7
8
250
All manuals and user guides at all-guides.com
RJ-48 Pin
(Data numbering
form)
4
5
3
6
No connect
No connect
RJ-48 Pin
(Data numbering
form)
4
5
1
2
3
6
No connect
No connect
Signal
TX, Ring, –
TX, Tip, +
Shield/Return/Ground
Shield/Return/Ground
No connect
No connect
Signal
RX/Ring/– <––>TX/Ring/–
RX/Tip/+ <––>TX/Tip/+
TX/Ring/– <––>RX/Ring/–
TX/Tip/+ <––>RX/Tip/+
Shield/Return/Ground
Shield/Return/Ground
No connect
No connect
Copyright © 2010, Juniper Networks, Inc.
